aluminum truss is a wide used frame strcuture in recent events.
it mainly fall into these catogries, lighting truss, stage truss, sound truss, speaker sound truss, led truss, dj truss, line array truss, pillar truss, tower truss, display truss, exhibition truss etc. based the location and function.
as it is lightweight and portable design, it is welcome by eventors.
Aluminum truss is a important structural material for event stages, It plays a main role in the truss works. Above all, safety comes first in all around a event, especially for the stage, thus the quality of the truss is the key point.
Why in these days, more and more event organizers and truss rental companies choose aluminium truss rather than iron truss?
Commercial activities are everywhere, and as economic development continues, various cultural activities, as well as commercial promotion and publicity activities, are being increased. With the expansion of the scale of such commercial activities, the use of stage trusses is also increasing. For any stage, stage trusses play a vital role. However, many people are unaware of the importance of stage trusses. This article will provide a brief analysis and introduction to stage trusses in relation to their functions and application scenarios.
Nowadays, aluminium alloy products are arguably one of the most used metal products. Aluminium is widely used in various fields thanks to its excellent strength and ductility. It is no exaggeration to say that aluminium alloy products are everywhere in our lives. The product we are going to introduce today is the aluminium alloy truss, which is a basic equipment widely used in large occasions. However, many people do not know what aluminium trusses are. This article will combine the basic knowledge of aluminium trusses and give you a brief introduction.
As the metalworking industry matured, different forms of metal products began to appear. Aluminium products, for example, have become one of the most utilised metals thanks to their excellent physical properties. The product we are going to introduce today is one of these aluminium products and it is the aluminium truss. This article will give a brief analysis and introduction to aluminium trusses. At the same time, the common types of aluminium truss will also be mentioned.
Aluminium trusses can be considered a very important modern facility and play a vital role in large events. Aluminium trusses have many advantages, being light, heavy-duty, and easy to move to any workplace. Aluminium trusses have become the first choice for large events. However, many people do not know how to install aluminium trusses properly. This article will focus on the correct steps and precautions for aluminium trusses installation.
6. What is lighting truss?With the innovation of science and technology, increasingly more metal products are appearing in people's lives. Different kinds of metal products are of great significance to people's lives. The product we are introducing today is a type of truss, it is a lighting truss. Having said that, some people may not know what lighting trusses are. In this article, we will give a brief introduction to lighting trusses in relation to their applications and characteristics. |
As people's quality of life has increased, their entertainment has begun to diversify and a variety of commercial activities have emerged. This is why the use of trusses is increasing. The truss is a prop with a wide range of applications. As a metal product, it can be made of either iron or aluminium, and Dragon Stage is a specialist in the design of trusses, with aluminium trusses as its main product. With its excellent physical characteristics, aluminium trusses are favoured by many companies. The product we are going to introduce today is the lighting truss, which is also one of the common trusses and its main function is to connect the stage lighting equipment.
With the development of the society, different kinds of materials and props started to appear on different occasions. Metal products made of different materials began to emerge due to the development of the metal processing industry, and trusses are a good example of this. In recent years, the growth in the number of large and small events at home and abroad has led to the use of trusses more and more. The product we are going to introduce today is light truss, which is a type of truss.
With the development of the times, more and more people are interested in how to use large equipment. Different types of large devices can play an important role in different situations. For example, in various activities or gatherings, the LED truss can set your mood and drive the rhythm. Truss is one of the main components of various activities, and its design is high for security and appearance. This article will focus on how to cleanLED truss.
With the development of the metalworking industry, more and more types of metal products are beginning to appear in people's lives. Metal products play a great role in modern industry, and today we are going to introduce metal products such as stage trusses, a kind of equipment that plays a great role in stage performance. The stage truss is an aluminum product and its applications and characteristics will be highlighted in this article.
Stage truss is a typical product of modern industry, it has a wide range of applications and can be considered as essential equipment for stage performances, it is a mover on-stage performances, not only as a stage performance to liven up the atmosphere, but also has a long service life. The characteristic of the stage truss will be highlighted in this article. In addition, some notes on the use of stage trusses will also be presented.
Stage performance is an art form that is also one of the main pastimes of modern people. In the history of human art, stage art has a long history. It first originated in human rituals, and then gradually developed into a comprehensive art with many constituent elements fused with each other. Nowadays, there are various ways to stage performances, and the product we are going to introduce today is related to stage art. It is the stage truss, an essential prop for stage performances. The installation methods and precautions for stage trusses will be described in this article.
Stage trusses are used by modern event planners whenever they build a stage for a big event. In some cases, aluminum stage trusses are now a regular product to make the stage more beautiful for the audience. Additionally, the aluminum stage truss provides a powerful corporate promotional tool for business events.
The aluminum stage truss is used in corporate exhibitions, sales promotions, recruitment, and various public events. The question may arise in your mind: how do I choose an aluminum stage truss to build a booth? Here are a few tips you can follow.
Lighting truss has so many applications that bring life to any party. Lighting truss allows lighting designers to hang static lights or automated fixtures in any location they choose. Lighting trusses are used everywhere lighting equipment is deployed. Let's find out how lighting truss works. After that, we will discuss the best lighting truss that is available for your use.
Lighting trussIt is a truss that is connected to the stage device to illuminate it, and can customize various shapes and sizes as needed. With the increase in commercial activities, the use of lighting truss is more frequent. This article will answer questions that know how to properly install a lighting truss.
The stage is the space provided in a theatre for the actors to perform, which allows the audience to focus on the actors' performance and obtain the desired viewing effect. The stage usually consists of one or more platforms. The product we are introducing today is related to the stage, it is the stage truss, a multifunctional prop that can be used in a wide range of applications. Although stage trusses are widely used, many people do not know how to use them, so this article will give a brief overview.
The truss is a very common piece of equipment in our lives, its main function is to provide support and to be used in various stage or performance applications. The truss we are going to introduce today is the lighting truss, which has been used to connect the stage lighting facilities.
·How to hang a lighting truss effectively?
·The development history of a lighting truss.
·The reasons for using a lighting truss.
18. how to hang lighting truss from ceilingIn fact, there are mainly two kinds of ceiling you may need to consider . So different ceiling you need different way to hang lighting truss from. 19. What is event truss?With the increasing quality of life, the entertainment options in life are becoming more diverse. For example, the various props used in stage performances can help people have a better entertainment experience. However, many people do not know what an event truss is. Basic information about the event truss, such as features and applications, will be mentioned in this article. 20. How to install event truss?How to build event truss?How to assemble event truss?Trusses are a common piece of load-bearing equipment that we see at concerts, proms, weddings and various large events. The advantage of trusses is that the rods are mainly subjected to tension or pressure, allowing the material to be used to its full potential, saving material and reducing the weight of the structure. The principle of a truss is also simple: it is a structure with a constant geometry made up of a number of triangular frames made of straight rods. Although the use of trusses is very common, many people do not know how to install event trusses. This article will give you a brief overview of the installation steps of an event truss and answer your questions. 21. What should be paid attention to when using event truss?The truss is a remarkably common piece of equipment, its greatest feature is the load capacity. Generally speaking, trusses can be used for all kinds of large events, not only bringing an aesthetic experience to the stage, but also allowing better interaction between performers and audience. The product we are going to introduce today is related to trusses, it is the event truss. In this article we will give a brief introduction to event trusses and some precautions on their use will be highlighted. 22. How to distinguish high quality and poor aluminum trussFirst of all, the high-quality aluminum truss are well welded with accurate dimensions, and There will be no misalignment of screw holes or mismatch between truss and accessories. The poor quality aluminum truss has rough welding, irregular shape, different sizes and unsightly welding joints. |
The DragonStage 10m × 7m × 6m Outdoor Flat Roof Stage Truss System is a modular event-stage package featuring a 10m main truss span, 7m stage depth, 6m overall truss height, and 2.5m-wide side wings. The stage platform uses 1.22m × 1.22m modular deck units and is supplied with guardrails on three sides and two access stairs for concert, festival and temporary outdoor event applications.
The DragonStage Ringlock LED Background Wall with Aluminum Brace Stage combines a 20m wide × 2m deep × 12m high Ringlock background structure with a 20m × 10m × 2m aluminum brace stage and two aluminum access stairs. Designed for concerts, festivals, ceremonies and large temporary productions where a tall stage-background structure is required for LED screen, visual backdrop or event presentation applications.
The DragonStage 14m × 6m × 8m Ringlock Truss Wall with 8m × 4m Aluminum Quick Stage combines a large modular Ringlock wall structure with a compact 0.8m-high aluminum quick stage and two access stairs. Designed for concerts, performances, ceremonies and temporary event installations, this configuration provides a large structural background around a practical modular performance platform.
The DragonStage 24m Ringlock Truss Wall with 12x12m Aluminum Roofing Stage and Two Front LED Wings is a large concert-style event structure that combines a full Ringlock wall framework, a central aluminum roofed stage, two front LED wing structures, and two aluminum access stairs. The overall Ringlock structure measures approximately 24m wide × 14m deep × 8m high, while the central roofed stage uses a 12m × 12m × 8m aluminum truss roof frame with a 12m × 10m stage platform and two 2m-high aluminum stairs.
The 4m × 6m DragonStage Channel Tent is a customized aluminum A-frame tent designed to create a covered passage between backstage or stage-side preparation areas and the main stage. It can be installed inside an opening intentionally reserved within a larger Ringlock structure, helping protect performers, staff, costumes and equipment from rain while providing a more private and clearly defined access route.
The 4m × 6m Built-In Hybrid Ringlock FOH Booth is a compact technical workspace designed for Front of House control, DJ operation, and event control-cabin use. It combines a Ringlock-integrated support concept with an aluminum roof frame, modular plank floor, roof tarpaulin, side curtains, and front/rear enclosure panels, making it suitable for integration inside larger event structures.
4m × 4m multi-level FOH control tower combining a modular Ringlock main structure with an aluminum single-slope roof frame. Maximum height is 7m, with a 6m low-side roof height and 7m high-side roof height. The package includes working platforms, aluminum ladders, roof and canopy tarpaulins, curtain enclosure, auxiliary base structure and related stabilization components for concert and event production
6m × 4m hybrid FOH control booth combining a modular Ringlock main structure with an aluminum single-slope roof frame, modular working platform, curtain enclosure, roof tarpaulin, and access ladder. Designed for concert, festival, and temporary event technical-control applications
2m × 0.5m steel Ringlock speaker tower top support beam made from 48.5mm round pipe, designed to connect the upper Ringlock tower structure with aluminum truss for line array and event audio support applications. Custom supplied by DragonStage
6m × 6m aluminum flat roof truss system with a 4m front height and 6m rear height, using a four-tower modular support configuration for concerts, lighting rigs, stage productions, and temporary event applications. Custom manufactured by DragonStage.
The 4m × 6m Hybrid Ringlock FOH Control Booth is a customized Front of House structure for concert, festival, live-event, and production-control applications.
The main booth structure is built from a modular Ringlock system, while the pitched roof uses a separate aluminum frame. This combination allows the booth body, working floor, enclosure, and roof components to be supplied as one coordinated temporary-event package.
The confirmed dimensions for this configuration are:
The structure also includes roof tarpaulins, side and rear/front curtain panels, aluminum roof beams, platform planks, diagonal bracing, and steel ballast-pipe components according to the supplied BOQ.
DragonStage supplies other modular temporary structures through our Ringlock Structure System product range.
The 4m × 4m Multi-Level Hybrid Ringlock FOH Control Tower is a customized Front of House control structure designed for concerts, festivals, live productions, and other temporary event applications.
This product combines a Ringlock main tower structure with an aluminum roof frame and weather-cover system, creating a compact but elevated technical-control tower for audio, lighting, video, or show-operation use.
The confirmed project dimensions are:
This makes it a sloped-roof hybrid FOH tower, with the roof rising from the lower side to the higher side.
According to the supplied BOQ, the structure includes the Ringlock main body, internal planks, ladder-access components, aluminum roof beams, side-wall curtain posts, roof tarpaulin, side and front/back curtains, ballast-pipe components, and a lower auxiliary base structure.
DragonStage manufactures customized temporary event structures through our Ringlock Structure System and Custom Stage Production services.
The 24ft × 24ft Flat Roof Aluminum Truss System is a customized four-tower event truss structure with a 20ft tower height, designed for temporary stages, lighting installations, concerts, performances, corporate events, and other event-production applications.
The system uses four vertical aluminum truss towers supporting a square flat-roof truss framework. Internal cross truss members divide the overhead area into multiple rigging zones, allowing the roof framework to be configured around the actual lighting and event-equipment layout.
The drawing also shows a tower lifting arrangement with sleeve blocks, allowing the assembled upper truss grid to be positioned on the vertical towers as part of the installation process.
DragonStage manufactures flat roof systems in different dimensions and configurations. See more products in our Typical Flat Roof Truss System range.
The 24m × 24m x6m Aluminum Truss Tent Structure is a customized outdoor covering solution designed for terraces, resorts, beach areas, hospitality spaces, and temporary event applications.
Based on the customer's requirements, this structure uses a 400mm aluminum screw truss system with a pyramid roof design, supported by 10 aluminum truss columns and covered with a white waterproof PVC tarpaulin.
The open-span design provides a large covered outdoor area while maintaining a clean architectural appearance suitable for outdoor events and commercial spaces.
DragonStage manufactures customized Aluminum Truss structures according to customer dimensions, application requirements, and project conditions.
This customized large tunnel event structure combines a 24m wide × 18m deep × 15m high tunnel aluminum truss system with a 21.96m × 14.4m × 2m high stage platform.
The upper structure uses multiple large curved aluminum truss arches connected by longitudinal truss sections, creating a wide-span architectural framework above the event area. The complete system can be supplied together with the elevated stage platform as a customized package for stadium events, ceremonies, concerts, festivals, and other large temporary productions.
The dimensions shown here come from an actual customer quotation requirement rather than a standard catalogue size.
DragonStage manufactures customized Roof Truss systems in different dimensions and configurations according to project requirements.
This 14m × 10m Ringlock concert stage system is a customized large-event stage package combining a steel Ringlock stage platform, aluminum peak roof truss, 6m-wide side structures for LED screens, and dedicated structures for line array suspension.
The main performance platform measures 14m × 10m, with a requested stage height of up to 2m. Ringlock scaffolding is also used to build the surrounding support structures up to approximately 10m high, matching the main stage and the 6m-wide wings on both sides.
Instead of purchasing the stage platform, roof truss, LED supports, and sound-support structures separately, customers can order them as one coordinated event-stage package from DragonTruss.
For other modular stage configurations, see our Ringlock Stage System.
2m × 2m modular Ringlock audience viewing platform originally configured for socially distanced concert seating areas. The system features a 0.2m-high aluminum pallet platform, three-sided double-rail guardrails, an open rear entrance, adjustable steel base jacks, and a front-facing position for event or sponsor posters.
This custom mobile DJ table is designed for a customer who needed one standalone DJ workstation rather than a complete stage system.
The table uses the same basic manufacturing logic as a professional aluminum stage platform: an aluminum frame, flat black working surface, rigid support structure, and replaceable modular components. However, instead of stage legs standing directly on the floor, this version is fitted with four lockable caster wheels so the complete table can be moved short distances inside a club without dismantling the DJ equipment.
The finished size is 2200mm wide × 800mm deep × 900mm high, providing a large working surface for multiple DJ players, a mixer, laptop, or controller.
For other aluminum platform products manufactured using similar structural principles, see our Aluminum Stage range.
DragonTruss manufactures integrated stage and truss systems combining modular aluminum stage platforms with aluminum truss structures for event applications.
This customized project includes a 9.76m x 9.76m Quick Stage main platform, a 2.44m wide x 3.66m long runway stage, and a 400x400mm spigot truss gantry structure with a 10m width and 5m height.
The system integrates a quick assembly stage platform with a modular truss framework, providing a complete structure solution for event decoration, lighting installation, and potential LED screen applications.
For customized stage structures combining platforms, truss systems, and accessories, DragonTruss provides complete Custom Stage Production services according to project requirements.
This custom black F34 curved truss arch structure was produced based on a customer's requested configuration, combining curved F34 truss elements, F32/F34 box corners, straight truss sections, and outdoor base plates.
Unlike standard straight truss products, curved truss structures require additional manufacturing coordination, including curve fabrication, connector alignment, component matching, and surface finishing. The final structure demonstrates DragonTruss's capability in producing customized aluminum truss solutions beyond standard configurations.
For projects requiring special shapes, customized layouts, or integrated stage structures, DragonTruss also provides Custom Stage Production services based on project requirements.
