36x18x12m Large Concert Stage with Multi-Tower Roof Truss System – 120x60x40ft
50 Reviews
The DragonStage 36x18x12m Large Concert Stage Roof Truss System is a large-format modular event structure featuring a multi-tower truss support system, an elevated overhead truss framework, and a modular stage platform with guardrails and stair access.
With nominal dimensions of 36m wide × 18m deep × 12m high (120ft × 60ft × 40ft), this configuration is intended for large concerts, music festivals, live performances, and temporary entertainment productions requiring an extensive stage area and overhead structural framework.
roof canopy material:pvc, Blue Colour or customized.
960.96
1pcs
Item
Specification(squre truss)
Qty
length
main tube(mm)
size(mm)
3.00 m Wings Beam
2 sets
3.00 m
50×5.0
CS680×1010
2pcs
2.00 m
50×5.0
CS680×1010
0pcs
1.00 m
50×5.0
CS680×1010
0pcs
11.00 m Wings Pillar
2 sets
3.00 m
FALSE
CS520×520
6pcs
2.00 m
FALSE
CS520×520
2pcs
1.00 m
FALSE
CS520×520
0pcs
Wings Tower
Spigot Sleeve Block L
2pcs
Steel Base L
2pcs
Top Section L
2pcs
Manual hoist,BA05 2Tons
2pcs
Spigot Hinge Section,Height 1m
2pcs
Fibre sling,BA04,2 tons 3m
2pcs
Long outrigger
8pcs
Truss Accessory
Conical coupler & Safrty clip & pin
whole set
Product Information
Item
Specification
Brand
DragonStage
Product Type
Large Concert Stage & Roof Truss System
Nominal Width
36m / 120ft
Nominal Depth
18m / 60ft
Nominal Overall Height
12m / 40ft
Structure Type
Multi-Tower Modular Truss System
Overhead Structure
Main Truss Beams with Transverse Members and Bracing
Support System
Vertical Truss Towers with Base Supports
Stage Platform
Modular Raised Stage, as illustrated
Stage Guardrails
Shown around selected stage edges
Stage Access
Stair Access Shown
Auxiliary Dimension
3m Offset Shown in Drawing
Roof Covering
Not Shown; Specification to Be Confirmed
Truss Material & Section Size
To Be Confirmed
Stage Platform Dimensions
To Be Confirmed from Final Drawing
Customization
Available According to Project Requirements
Product Description
The DragonStage 36x18x12m Large Concert Stage Roof Truss System is a large-format modular stage configuration designed for concert and event production environments.
The illustrated system combines a series of vertical truss towers, horizontal truss beams, transverse members, diagonal bracing, and a raised modular stage platform.
The main structure is specified with nominal overall dimensions of:
36m Wide × 18m Deep × 12m High
120ft × 60ft × 40ft
The overhead framework is arranged across a large performance area, with multiple truss members connecting the main structural sections.
Below the truss structure is a modular stage platform featuring a repeated deck layout, perimeter guardrails, and stair access.
This configuration is intended for customers who need a complete event-stage arrangement rather than purchasing individual truss beams and stage platforms separately.
A stage of this nominal size is intended for event productions where a conventional small stage is insufficient.
Potential applications include:
Large outdoor concerts
Music festivals
Live entertainment productions
Cultural performances
Touring concert productions
Large temporary event stages
Public entertainment events
Special event productions
The 36m nominal width provides a broad structural layout, while the 18m depth allows the overhead framework to extend across a substantial event-production area.
The actual usable stage area and clear internal dimensions must be confirmed from the final drawings.
Multi-Tower Roof Truss Support System
One of the defining features of this configuration is its multi-tower structural arrangement.
Unlike smaller roof truss systems that may use four main support towers, the illustrated structure includes multiple vertical tower positions connected through the overhead truss framework.
The main visible structural elements include:
Vertical truss towers
Main horizontal truss beams
Transverse truss members
Diagonal bracing
Tower-top connection assemblies
Base support assemblies
Auxiliary structural sections
The additional tower positions and connections allow the structure to be configured as a larger integrated system.
The precise number of towers, their spacing, truss sections, and structural capacities must follow the final project drawings.
Overhead Truss Framework
The overhead structure uses interconnected truss members rather than a single continuous horizontal beam.
The visible framework includes main truss members, repeated transverse beams, diagonal elements, and multiple structural connection points.
This arrangement can form the basis of a large event roof-truss system.
A roof covering is not shown in the current drawing. Any proposed roof membrane, weather enclosure, or suspended production equipment must be specified separately and assessed as part of the complete structure.
The supplied drawing includes a separate 3m dimension between two adjacent support positions.
This should be treated as an auxiliary layout dimension rather than automatically added to the nominal 36m overall width.
Before production, the final drawing should establish whether this auxiliary section is included within the stated footprint or extends beyond it.
Its exact structural function and components should also be confirmed.
Modular Manufacturing and Supply
For large event structures, a complete system cannot be specified only by its external dimensions.
The final supply package depends on the structural layout and component requirements.
DragonStage can discuss the manufacture and supply of truss modules, tower components, connections, stage platforms, guardrails, access stairs, and related hardware according to the confirmed configuration.
A detailed bill of materials can then identify each component type, quantity, and specification.
Main Features
Nominal 36m × 18m × 12m overall configuration
Nominal imperial size 120ft × 60ft × 40ft
Large-format concert-stage arrangement
Multiple vertical truss support towers
Extensive overhead truss framework
Main beams and transverse truss members
Diagonal structural bracing
Modular stage platform
Illustrated stage guardrails and stair access
Auxiliary 3m support offset shown
Modular component-based configuration
Custom manufacturing and system supply options
Important Technical Note
The confirmed information consists of the requested nominal dimensions and structural elements visible in the drawing.
The supplied drawing does not establish:
Verified roof-truss load capacity
Maximum lighting or equipment suspension load
Wind resistance
Ballast or anchoring requirements
Foundation specifications
Stage allowable load
Roof covering specification
Verified component quantities
Project-specific engineering approval
The final configuration requires confirmation of the truss material, section sizes, connections, equipment loads, environmental conditions, ground conditions, and applicable project requirements.
The nominal 12m overall height should not be interpreted as a confirmed clear height beneath every part of the overhead structure.
FAQ
What is the overall size of this concert stage system?
The nominal overall dimensions are 36m wide × 18m deep × 12m high, corresponding to the commercial imperial size designation 120ft × 60ft × 40ft.
Does the product include a stage platform?
The illustrated configuration includes a modular stage platform with visible guardrails and stair access. The final stage package and component quantities should be confirmed before quotation.
What type of roof structure is shown?
The drawing illustrates a large overhead truss framework supported by multiple vertical truss towers, with transverse beams and bracing members.
Is a waterproof roof covering included?
A roof covering is not shown in the drawing. Any membrane or weather-protection package must be separately specified and confirmed.
Can lighting and sound equipment be suspended from the overhead truss?
Such equipment may form part of the intended event-production use, but allowable loads and suspension positions cannot be established from the image alone. They require project-specific verification.
What does the additional 3m dimension represent?
The drawing shows a 3m auxiliary spacing between support positions. Its relationship to the 36m nominal overall width and its structural function must be confirmed in the final drawing.
Can the stage and truss dimensions be customized?
Different dimensions and configurations can be discussed. Any change to the nominal width, depth, or height may affect tower positions, truss members, connections, and the supporting arrangement.
Can this structure be used outdoors?
Outdoor suitability depends on the complete configuration, including the site, wind exposure, roof covering, attached equipment, ground conditions, and the required structural verification.
Does the system use modular truss components?
Yes. The illustrated system is assembled from multiple truss sections and connection assemblies rather than one permanently fabricated unit. Exact connection types must be confirmed.
Can DragonStage supply the stage and truss as one package?
DragonStage can discuss coordinated supply of the stage and truss components according to a confirmed drawing and bill of materials.
Why Choose DragonStage
DragonStage manufactures and supplies modular stage and truss systems for temporary event applications.
For large concert stages, coordinating the truss framework, support towers, stage platform, access components, and installation requirements is important to preparing a complete and accurate equipment package.
Our approach is to establish the required configuration and component specifications before finalizing manufacture and supply.
Request a Quotation
For a detailed quotation, please provide:
Required overall width, depth, and height
Event location and indoor/outdoor application
Roof covering requirements
Lighting, sound, LED, and other equipment details
Equipment weights and proposed installation positions
Stage platform dimensions and height
Guardrail and stair requirements
Ground and installation conditions
Required quantity
DragonStage can then review the intended configuration and prepare a corresponding manufacturing and supply proposal.
