290mm Spigot Black Curved Roof Truss System with Box Corners And Outdoor Base Plates
50 Reviews
This custom black F34 curved truss arch structure was produced based on a customer's requested configuration, combining curved F34 truss elements, F32/F34 box corners, straight truss sections, and outdoor base plates.
Unlike standard straight truss products, curved truss structures require additional manufacturing coordination, including curve fabrication, connector alignment, component matching, and surface finishing. The final structure demonstrates DragonTruss's capability in producing customized aluminum truss solutions beyond standard configurations.
For projects requiring special shapes, customized layouts, or integrated stage structures, DragonTruss also provides Custom Stage Production services based on project requirements.
Curved truss structures are widely used when a project requires a unique visual design or special structural layout that cannot be achieved with standard straight truss sections.
Compared with conventional straight truss, curved truss manufacturing requires careful control of:
Curve angle and radius
Connection point accuracy
Matching between curved and straight components
Transportation and installation requirements
DragonTruss can manufacture customized truss structures according to customer requirements, including curved sections, special shapes, and combined truss systems.
F34 Modular Truss System
This structure is based on the F34 truss system and integrates F32/F34 components to create a flexible modular configuration.
The system includes:
Curved F34 truss elements
F34 box corners
F32 box corners
Straight F32/F34 truss sections
Outdoor fixing base plates
The modular connection principle allows different truss components to be combined for different project requirements.
More information about truss connection and structural integration can be found in:
The entire truss structure uses a black powder-coated finish to achieve a professional appearance for stage and event environments.
Powder coating requires proper surface preparation and production control, including:
Surface cleaning
Pretreatment
Powder application
High-temperature curing
DragonTruss provides different finishing options for aluminum truss structures, including natural aluminum finish and customized powder coating colors.
Manufacturing Process
Requirement Confirmation
Before production, DragonTruss confirms:
Required truss configuration
Component combination
Connection requirements
Surface finishing requirements
Installation conditions
Customers can provide drawings, sketches, reference images, or component lists. DragonTruss evaluates the requirements and develops a suitable manufacturing solution.
Curved Truss Production
Curved aluminum truss requires specialized fabrication to ensure that each section matches the required shape and connection system.
Manufacturing considerations include:
Maintaining consistent curvature
Ensuring connector alignment
Matching curved and straight sections
Preparing components for efficient installation
Quality Inspection
Before shipment, truss components are checked according to production requirements, including:
Component dimensions
Connection accuracy
Surface finishing quality
Accessories completeness
DragonTruss applies practical manufacturing experience together with systematic production control to ensure the final structure meets the customer's configuration requirements.
Applications
This type of customized curved truss structure can be used for:
Stage and Event Structures
Suitable for customized stage environments requiring special visual effects and flexible layouts.
The modular aluminum truss system can be used for:
Lighting support
Event decoration
Branding structures
Temporary installations
Customized Temporary Structures
For projects requiring non-standard shapes or special combinations, DragonTruss provides manufacturing support from component selection to final production.
Custom Manufacturing Capability
DragonTruss specializes in customized aluminum truss manufacturing, supporting customers with:
Custom curved truss
Special-shaped truss structures
Customized powder coating
Different connection configurations
Project-based truss solutions
For customized projects, please provide:
Structure drawing or reference image
Overall dimensions
Required truss type
Installation environment
Quantity requirement
Our engineering and production experience helps customers transform concepts into manufacturable truss systems.
Can DragonTruss manufacture curved F34 truss structures?
Yes. DragonTruss manufactures customized curved aluminum truss sections according to customer requirements, including different angles, shapes, and connection configurations.
Can curved truss be combined with standard straight truss?
Yes. Curved truss sections can be combined with standard straight truss components when the dimensions and connection systems are properly matched.
Can aluminum truss be powder coated black?
Yes. DragonTruss provides black powder coating and other customized finishing options according to customer requirements.
What information is required for a custom truss quotation?
