Versatile Applications of LED Stage Trusses & Structures

Concerts & Music Festivals

Securely support LED screens and stage lighting.
Corporate Events & Conferences

Ensure a professional and sleek LED stage structure
Exhibitions & Trade Shows

Enhance brand visibility with a dynamic LED display stage
Sports Events & Outdoor Advertising

Provide stable LED video walls for large audiences
Theater & Entertainment Shows

Perfect for theatrical productions, fashion shows, and themed performances

Types of LED Stage Trusses & Structures We Offer

We mainly provide 3 kinds of led stage trusses & structures, which can be designed according to customers requirements.

LED Hanging Truss

LED Screen Rigging Kits is Adjustable hoist systems for overhead installations.
Keywords: LED screen rigging, LED screen hoist system, truss rigging for LED walls

Goal Post LED Truss: Versatile Overhead Support for AV Installations

A Goal Post LED Truss is a robust aluminum framework engineered in a "goal post" configuration—two vertical columns connected by a horizontal crossbeam. Designed for durability and modularity, this structure provides a secure overhead rigging solution for suspending LED screens, speakers, stage lighting, and other AV equipment. Its lightweight yet high-strength aluminum construction ensures portability and ease of assembly, while the open design maximizes accessibility for technicians.
Key Features & Applications:
Goal Post Design: Ideal for creating wide, stable frames over stages, entrances, or exhibition spaces.
Multi-Purpose Rigging: Supports hanging LED walls, line arrays, spotlights, and decorative elements.
Adjustable Height/Width: Modular components allow customization for venue-specific requirements.
Quick Setup: Bolt-together assembly with standardized connectors for fast deployment.
Event-Ready: Perfect for concerts, festivals, corporate events, and trade shows.
Built to handle heavy loads safely, the Goal Post LED Truss combines practicality with professional-grade performance, making it a go-to choice for event production teams and rental companies.

Layher Hanging LED Structure: Robust Overhead Rigging for Heavy-Duty Installations

The Layher Hanging LED Structure is a purpose-built modular framework, engineered to safely suspend large LED screens, lighting rigs, and AV equipment from its top beams. Designed for stability and versatility, this structure combines Layher’s signature steel or aluminum components—interlocking ledgers, standards, and diagonal braces. Its modularity allows seamless adaptation to venue dimensions and technical requirements.
Key Features & Applications:
Layher Scaffolding System: Engineered for strength, with connectors and steel decks for secure overhead mounting.
Top-Beam Rigging: Dedicated attachment points for hanging LED walls, projectors, or speaker arrays.
Adjustable Configurations: Expand horizontally or vertically to fit stages, arenas, or exhibition halls.
Rapid Assembly: Boltless locking system and pre-fabricated parts enable quick, tool-free setup.
Safety Compliance: Tested for dynamic loads, vibrations, and long-term installations.
Built to meet the demands of high-profile events and complex AV setups, the Layher Hanging LED Structure offers unmatched durability and flexibility.

Stage LED Wing Truss: Dynamic Side-Mounted Support for Immersive Visuals

The Stage LED Wing Truss is an integrated stage framework featuring dual vertical "wings" extending from the sides of a primary truss structure. Designed to enhance stage aesthetics and functionality, these wings incorporate high-strength aluminum beams at their tops. Perfect for creating immersive side-stage visuals or multi-dimensional displays, this system seamlessly integrates with the main stage truss while offering dedicated rigging points for dynamic setups.
Key Features & Applications:
Dual Wing Design: Symmetrical side structures for balanced LED screen or lighting installations.
Top-Beam Rigging: Reinforced aluminum beams with secure mounting points for hanging LED panels, projectors, or moving lights.
Modular Integration: Compatible with main stage trusses for scalable configurations (e.g., 8m+ spans).
Quick Deployment: Pre-assembled wing units with standardized connectors for rapid on-site assembly.
Built to elevate stage design flexibility, the Stage LED Wing Truss empowers production teams to deliver visually striking, multi-angle experiences while maintaining structural reliability and ease of use.

LED Stacking Truss

Base Plates & Braced Frames Stabilize LED screens from solid ground or platform.

Keywords: Ground support for LED screen, Stackable LED truss, Modular stacking truss for LED

LED Ladder Stacking Truss

LED ladder stacking trusses play a crucial role in supporting LED walls for various events, exhibitions, and performances. These trusses provide a strong and stable back support structure, ensuring LED screens remain upright and secure. They are designed to withstand outdoor and indoor environments while offering modular flexibility for different stage setups.

Types of LED Ladder Stacking Truss
LED ladder stacking trusses mainly fall into two categories based on their connection method:
Spigot Connector & Pin System
Uses spigot connectors and pins to link truss sections together.
Offers quick assembly and disassembly, making it ideal for rental and touring setups.
Provides high stability with secure locking mechanisms.
Handle Lock System
Features handle locks that provide a tool-free connection.
Ensures fast installation, reducing labor time on-site.
Commonly used in smaller LED wall setups where speed is a priority.

Material & Design Features
Aluminum Alloy Construction: The ladder stacking truss is typically made of high-strength aluminum alloy, ensuring durability, lightweight properties, and corrosion resistance.
Modular Length Design: Different manufacturers offer standard modular lengths, allowing easy customization and scalability for various stage dimensions.

Structural Components of Ladder Stacking Truss
Main Support Structure
The ladder stacking truss serves as the primary back support frame for LED walls.
It maintains screen stability, preventing tipping or misalignment.
Adjustable Back Brackets
These reinforcement brackets are adjustable to accommodate different LED wall heights and angles.
They help hold the LED screen straight up from the ground, ensuring proper alignment.
Steel (or Aluminum) Base Frame
The base frame is crucial for counterbalancing the weight of the LED wall.
Steel bases offer higher load capacity, while aluminum bases provide lightweight advantages.
Ground Beam for Leveling
The ground beam helps in leveling the bottom row of LED panels.
It ensures a perfectly aligned base, reducing pressure on the LED modules.

Applications of LED Ladder Stacking Truss
Concerts & Live Events: Ensures a stable back structure for large LED displays.
Trade Shows & Exhibitions: Provides a modular and portable LED support system.
Outdoor Advertising & Sports Events: Offers a weather-resistant solution for outdoor LED screens.
Corporate & Theatrical Productions: Supports high-quality visual presentations with quick setup capabilities.

LED Frame Stacking Truss

LED frame stacking trusses are essential for supporting LED walls in various events, exhibitions, and performances. These trusses provide a flexible and stable back support structure, designed to adapt to different stage setups. Made from high-strength aluminum alloy, these trusses ensure durability, lightweight properties, and ease of installation.

Types of LED Frame Stacking Truss

LED frame stacking trusses mainly fall into five categories, each designed for specific support functions:

Independent Back Support Truss Pillar
A standalone pillar structure providing vertical stability.
Ideal for small to medium LED walls.

“日” Shape Back Support Frame
A rectangular H-frame structure ensuring even weight distribution.
Suitable for medium to large LED wall setups.

“田” Shape Back Support Frame
A grid-like frame structure for extra reinforcement and stability.
Best for large-scale LED wall installations.

Square Base Truss System
Features a square base frame for additional support.
Helps to counterbalance the LED wall’s weight.

Square Pillar Truss Stacking System
Uses stacked square trusses to form a multi-layered support system.
Ideal for high and wide LED walls needing extra stability.

Applications of LED Frame Stacking Truss

Concerts & Live Events: Provides sturdy support for large LED screens.
Trade Shows & Exhibitions: Ensures a secure and professional LED display setup.
Outdoor Advertising & Sports Events: Offers a weather-resistant and durable solution.
Corporate & Theatrical Productions: Supports high-quality visual presentations with quick installation.

The LED frame stacking truss is a versatile and essential component for modern LED screen installations. With different structural designs such as independent pillars, “日” and “田” shaped frames, square base, and square pillar stacking systems, these trusses ensure stability, flexibility, and safety. Choosing the right stacking truss system depends on event requirements, LED wall size, and load capacity to achieve a seamless and secure LED display setup

Structural Components of LED Frame Stacking Truss

1. Main Support Structure, Provides the primary framework for LED walls. Ensures stability and weight distribution.

2. Adjustable Back Brackets, Allow customization of LED wall angles and height. Help hold the LED wall straight up from the ground.

3. Steel (or Aluminum) Base Frame, Acts as a counterweight system to balance the LED screen. Steel bases provide higher load capacity, while aluminum bases ensure lightweight flexibility.

4. Ground Beam for Leveling, Ensures a stable and even base for the bottom LED panels. Prevents misalignment and uneven weight distribution.

Led Layher Stacking Truss

LED Layher stacking trusses are essential for supporting LED screens in large concerts and events. Unlike traditional stacking systems, this method utilizes a layer truss system combined with supplementary components to form a stable and secure structure. The primary difference among these systems lies in the base material, which determines the structural stability and installation method.

Types of LED Layher Stacking Truss

LED Layher stacking trusses mainly fall into four categories, each designed for specific load-bearing and installation requirements:

1. Square Straight Steel Tube Base
Constructed using square steel tubes, offering high durability and load capacity.
Requires LED screen brackets to support and secure the screen.
Ideal for fixed and semi-permanent installations.
2. Steel Pallet Base System
Features a convex structure with a pallet top to hold the LED screen.
Provides greater weight distribution and stability on uneven surfaces.
Commonly used for large outdoor concerts and events.
3. Layher Stage System
Directly integrates the LED screen stacking system with the performance stage.
Simplifies setup and dismantling, making it suitable for temporary installations.
Best for concerts, festivals, and large-scale productions.
4. Temporary Base Systems
Uses the same design as the steel pallet base, but replaces the pallet with alternative materials.
Common materials include plywood, aluminum square trusses, and other lightweight structures.
Designed for quick assembly and ease of transport.

Structural Components of LED Layher Stacking Truss
1. Main Support Framework
Provides a stable backbone for the LED wall structure.
Ensures load distribution and resistance against wind and external forces.
2. Adjustable Brackets and Fasteners
Allow customization of LED panel height and angle.
Enhance structural integrity and screen alignment.
3. Heavy-Duty Base Frame
Acts as the foundation for weight balancing and stability.
Materials vary from steel, aluminum, and plywood-based systems.
4.Interlocking Ground Beams
Help level the LED wall structure and prevent misalignment.
Ensures a secure and even bottom panel alignment.

Applications of LED Layher Stacking Truss

Concerts & Music Festivals: Provides strong and scalable LED wall support.
Sports & Outdoor Events: Ensures a secure and weather-resistant LED display setup.
Trade Shows & Exhibitions: Offers a flexible and modular solution for LED screen installations.
Corporate & Theatrical Productions: Supports high-quality presentations with reliable structural integrity.

LED Mobile Truss

Wheeled LED Kits & Structural Frames engineered for hanging LED screens that require effortless relocation, these mobile systems combine wheeled bases and modular frames to enable quick repositioning across venues. Integrated crank stands or adjustable legs ensure stability and height customization during transport or live use.
Keywords: Rolling LED truss, LED truss with wheels, LED crank stand, portable LED truss.

LED mobile trusses are engineered for effortless relocation, providing a highly adaptable solution for dynamic event setups and live productions. These systems integrate wheeled bases and modular frames, allowing quick repositioning across venues while maintaining stability and ease of use.

Features of LED Mobile Truss
1. Wheeled LED Kits
Designed for fast mobility, enabling smooth transportation within a venue.
Wheels feature locking mechanisms to ensure stability when stationary.
2. Structural Frames for Hanging LED Screens
Engineered to support various LED screen sizes and weights.
Made from durable aluminum alloy or steel to balance strength and portability.
3. Integrated Crank Stands & Adjustable Legs
Height customization allows for optimal LED screen positioning.
Provides stability during both transport and live use.

Structural Components of LED Mobile Truss
1. Modular Support Framework
Enables easy assembly and disassembly, making transport more efficient.
Designed for compatibility with different LED display configurations.
2. Wheeled Base System
Equipped with heavy-duty casters for smooth movement.
Locking wheels prevent accidental shifting during operation.
3. Height-Adjustable Mechanism
Uses crank-operated or hydraulic lifts for precise height adjustments.
Ensures optimal visibility and audience engagement.
4. Quick-Connect Fasteners
Allows for rapid setup and teardown, reducing labor time.
Enhances structural integrity by securing truss connections.

Applications of LED Mobile Truss
Concerts & Touring Events: Enables quick screen movement between performance areas.
Corporate Conferences & Exhibitions: Facilitates seamless reconfiguration of digital displays.
Sports Events & Outdoor Advertising: Provides flexible positioning for real-time audience engagement.
Temporary Installations & Roadshows: Ensures fast deployment in various locations.

The LED Mobile Truss System offers a versatile and efficient solution for LED screen installations requiring frequent repositioning. With wheeled bases, modular frames, and adjustable supports, this system enhances mobility, stability, and ease of use across different events. Choosing the right mobile truss setup depends on venue requirements, LED display size, and transport logistics, ensuring a seamless and adaptable experience for any event.

How to Set Up an LED Stage?

Setting up an LED stage requires careful planning to ensure stability, visibility, and performance efficiency. Whether you're preparing for a concert, corporate event, or exhibition, follow these steps to create a safe and visually impactful LED stage.

Choose the Right Truss System

As the backbone of LED stage. Consider the following when selecting a truss:
Screen Size & Weight – Ensure the truss system can handle the load capacity of the LED panels.
Event Type & Venue – Outdoor events require weather-resistant trusses, while indoor setups may need lighter, modular designs.
Rigging & Mounting Needs – Options include ground-supported trusses, hanging trusses, or mobile truss systems for flexible setups.

Ensure Stability & Safety

For large LED stages, structural stability is crucial to prevent accidents. Follow these guidelines:
Reinforced Ground Support – Use steel base plates, counterweights, or guy wires to prevent tipping.
Wind Load & Weather Protection – Outdoor setups should account for wind resistance and rain protection.
Secure Cabling & Power Supply – Avoid loose cables and ensure a stable power source to prevent flickering or outages.

Optimize Screen & Lighting Placement

Proper LED screen and lighting positioning enhances audience engagement and prevents visibility issues. Keep these factors in mind:
Avoid Glare & Reflection – Adjust screen angles to minimize direct light interference.
Maximize Viewing Angles – Position LED panels at an optimal height for wide audience coverage.
Integrate Stage Lighting – Balance brightness to avoid overexposure or shadowing on performers.
