A

Yes, but wind load, ballast, anchoring methods, and local regulations must be considered.

A

Yes. Aluminum and steel modular structures are designed for repeated assembly and transportation.

A

Yes. Stage size, height, roof type, stairs, ramps, and platforms can all be customized.

A Yes. We can customize outdoor stage roof systems according to span, stage size, hanging load, wind requirements, and site conditions.

A

A

A

A

A

A

Lighting trusses are widely used in concerts, exhibitions, trade shows, churches, theaters, TV studios, DJ booths, weddings, brand events, sports events, and outdoor festivals.

They can be used to support lighting fixtures, speakers, LED screens, banners, curtains, decorative elements, and temporary event structures.

Depending on the application, the truss system may be designed as a hanging truss, ground support structure, roof system, booth frame, LED support frame, entrance arch, or custom event structure.

A

Yes. Aluminum truss can be used outdoors, but the structure must be selected and installed according to the actual site conditions.

Outdoor truss projects may be affected by wind, rain, ground conditions, hanging equipment, LED screens, banners, and roof covers. These factors can greatly change the load and safety requirements.

For outdoor structures, we recommend confirming the span, height, ballast or anchoring method, equipment load, and local weather conditions before installation. For larger outdoor systems, professional engineering review may be required.

A

Although some trusses may look similar, their prices can vary because of differences in material, wall thickness, connection method, production process, and load requirements.

For example, 6061-T6 and 6082-T6 aluminum have different raw material costs. A truss with thicker tubes or stronger connectors will also cost more than a lighter-duty version.

Connection methods also affect the price. Some trusses use welded connections, some use extruded aluminum connectors, and some may use aluminum structures with steel bolt-and-rivet components. These different structures require different materials, labor, machining, and quality control.

Similar appearance does not always mean the same specification, strength, or service life. Price comparisons should be based on material, tube thickness, connection design, load capacity, and intended application.

A

Yes. We can manufacture curved trusses, circular trusses, arches, and other special truss shapes according to project requirements.

Curved trusses are commonly used for stage designs, exhibition booths, entrance arches, circular lighting rigs, wedding decoration, and brand displays.

To quote and design correctly, we usually need the diameter, radius, arc angle, truss section size, connection type, and intended use. If you already have drawings or reference photos, please send them to us for evaluation.

A

Yes. Custom truss lengths can be manufactured according to your project requirements.

Custom lengths are useful when standard 1m, 2m, or 3m sections cannot match the exact site dimension, LED screen size, booth structure, or installation layout.

Before production, we recommend confirming the full structure layout, connection method, and total span. This helps ensure that the custom truss can connect correctly with the rest of the system.

A

Our standard aluminum truss lengths usually include 1m, 2m, 2.5m, 3m, and 4m, depending on the truss series.

Common lengths are easier to combine, replace, transport, and reuse in different projects. For most stage, exhibition, and event structures, standard lengths are recommended whenever possible.

If your project requires a special length, we can also manufacture custom lengths according to your drawings or layout requirements.

A

Yes. Aluminum trusses can be powder coated in black or other customized colors.

Black truss is commonly used for concerts, theaters, churches, exhibitions, TV studios, and events where the structure needs to blend into the background or match the visual design.

Please note that powder coating may require additional production time and cost. For large orders or specific color requirements, please provide the RAL color code or reference sample before production.

A

Yes. We can manufacture aluminum trusses using 6061-T6 or 6082-T6 aluminum alloy, depending on the project requirement and customer preference.

6061-T6 is commonly used for many standard aluminum truss products. 6082-T6 is also available and is often selected for projects requiring higher material specifications or specific market requirements.

The material cost of 6061-T6 and 6082-T6 is different, so the final price may vary depending on the alloy grade, tube size, wall thickness, and order quantity.

A

Compatibility depends on the truss series, dimensions, connection type, and connector specifications.

Even if two trusses look similar, different manufacturers may use different tube spacing, connector sizes, pin holes, or corner designs. Before confirming compatibility, we recommend checking the existing truss drawings, photos, or detailed measurements.

If you want to connect our truss with an existing system, please provide the brand, model, section size, connector type, and key dimensions. We will help evaluate whether it can be matched or customized.

A

The load capacity of aluminum truss depends on the truss size, span, material, wall thickness, connection type, support method, and how the load is applied.

For example, a short truss span may support more weight than a long span. A roof structure, hanging truss, LED support frame, and decorative booth truss may also require different load considerations.

If your project involves lighting fixtures, speakers, LED screens, or outdoor use, please provide the span, height, equipment weight, and installation method. We can then recommend a suitable truss size and configuration.


A Yes, in many cases we can design and manufacture a roof truss system to work with your existing truss structure.

However, compatibility should always be carefully verified before production. Different manufacturers may use different:

Truss dimensions
Main tube sizes
Brace layouts
Connection systems
Connector dimensions
Pin and coupler specifications

To evaluate compatibility, we normally require:

Overall truss dimensions
Detailed dimensions of the main tubes and braces
Connector and pin dimensions
Photos of the existing truss
Drawings or part numbers, if available

For some systems, adapter components or customized parts may be required to ensure proper fit and structural integrity.

Our recommendation is to confirm all dimensions before production rather than relying only on appearance or brand names.

Please note

Even trusses that look similar or come from the same country may have different specifications. Therefore, we strongly recommend confirming the dimensions of the existing system before manufacturing.

A

The required chain length mainly depends on the height of the truss tower and the installation method.

Common chain lengths for manual chain hoists are:
6 m
8 m
10 m
12 m

As a general rule, the chain length should be at least equal to the lifting height of the tower. Additional length may be required to allow for installation clearance and easier operation.

For example:

If standard chain lengths are not suitable for your project, we can provide custom chain lengths according to your requirements. In many cases, special chain lengths can be supplied without additional manufacturing charges.

To recommend the most suitable chain length, please provide:
Tower height
Truss type
Hoist capacity
Indoor or outdoor application

A

The rigging method for aluminum truss systems depends on many factors, including the truss span, suspended load, support structure, hoist capacity, and installation environment.

Before rigging a truss system, the following should be considered:

Truss dimensions and load capacity
Weight of lighting fixtures, speakers, LED screens, and other equipment
Number and location of suspension points
Hoist specifications and lifting capacity
Supporting structure and anchor points
Wind conditions for outdoor installations
Local safety regulations and engineering requirements

Common lifting equipment may include:

Chain hoists
Electric hoists
Shackles
Slings
Clamps
Rigging hardware

For larger structures and roof systems, installation should be performed by qualified personnel with appropriate equipment and safety procedures.

If required, we can provide layout drawings and recommendations based on the project requirements.

A Quick Truss is a lightweight aluminum truss system designed for fast, simple, and secure assembly. It uses solid conical connectors, tapered pins, and R-clips, allowing sections to be connected quickly without complicated tools or lengthy installation procedures.

Despite its compact size and low weight, Quick Truss provides excellent load capacity and structural stability, making it suitable for a wide variety of applications.

Common applications include:

Retail displays
Trade shows and exhibition booths
Decorative structures
Entrance arches
Lighting supports
Brand activation events
TV studios
Temporary event structures

Quick Truss systems are typically connected using conical connectors with pins and R-clips, providing fast assembly and easy transportation.

Standard lengths are available, and custom lengths, junctions, corner blocks, and curved sections can also be manufactured according to project requirements.

Why choose Quick Truss?

Compared with larger heavy-duty truss systems, Quick Truss offers:

Faster installation and dismantling
Lightweight construction
Compact transportation size
Good load capacity for small and medium-duty applications
Flexible configurations and custom shapes
Reusability for repeated events

Typical configurations include:

Straight sections
Curved trusses
Circular structures
Corner blocks and junctions
Exhibition booth frames
Decorative truss systems

The exact size and configuration depend on the project requirements and loading conditions.

A A book corner is a special truss connection component designed to create adjustable angles between two truss sections.

Unlike fixed corner blocks, book corners allow the angle between the connected trusses to be adjusted from 0° to 180°, making them suitable for structures that require flexibility or non-standard layouts.

Book corners are commonly used for:

Exhibition booths
Entrance arches
Curved and polygonal structures
Decorative truss designs
Stage backdrops
Custom event structures

Depending on the truss system, book corners may be designed to work with:

Female receivers and conical connectors
Half connectors and bolts
Spigot truss systems
Bolt truss systems

By using a rigid aluminum hinge frame, book corners provide both adjustability and structural reliability while allowing greater freedom in design.

A Truss cubes and corner blocks are special connection components used to create multi-directional truss structures and replace traditional welded junctions.

Unlike fixed welded intersections, truss cubes provide greater flexibility and allow users to configure the structure according to the project requirements.

Depending on the design, truss cubes can be used to create:

2-way junctions
3-way junctions
4-way junctions
5-way junctions
6-way junctions

By installing female receivers or connectors on different faces, a single cube can be configured into various structural arrangements.

Common Applications

Truss cubes and corner blocks are commonly used for:

Exhibition booths
Stage roof systems
Box truss structures
Lighting grids
Entrance arches
Speaker towers
Decorative structures
Custom event installations

They provide a modular alternative to standard welded junctions and make transportation, assembly, and future modifications easier.

Advantages of Truss Cubes

Compared with permanently welded junctions, truss cubes offer several advantages:

Greater flexibility
Easier transportation
Faster assembly
Reusable configurations
Expandable structures
Simplified maintenance and replacement

This makes them particularly suitable for temporary event structures and projects that require different layouts.

Standard Configurations

Common cube configurations include:

200 mm cube
290 mm cube
400 mm cube
Custom cube sizes

Depending on the project requirements, custom corner blocks and cubes can also be manufactured.

Cube vs Welded Junction

Traditional welded junctions provide a fixed geometry and are suitable for permanent designs.

Truss cubes, on the other hand, offer modularity and allow structures to be reconfigured into different shapes without manufacturing a completely new junction.

A

A

A

A

Lighting trusses can be classified according to their shape and connection method.

By Shape

Depending on the structural design and application, common truss types include:

By Connection Method

According to the connection system, lighting trusses are generally divided into:

Different truss types offer different advantages in terms of load capacity, assembly speed, transportation, and appearance. The most suitable type depends on the span, equipment load, installation environment, and project requirements.
