The BS400 curved and custom shape bolt-connected aluminum truss system is developed for projects requiring special geometry, such as curved lighting structures, entertainment venue installations and customized mechanical frameworks.
Based on the standard 400mm × 400mm square truss profile, the system uses 50mm aluminum round tube main chords combined with bolt-connected joints to achieve flexible structural layouts.
Compared with standard straight truss sections, curved and irregular BS400 structures provide greater design flexibility for:
Bar lighting designs;
Entertainment venue decoration;
Customized stage structures;
Special mechanical support frameworks.
Main Features
Customized Curved Design
The BS400 system can be fabricated into:
Circular arc structures;
Curved lighting rings;
Special angle connections;
Irregular decorative frameworks.
The curved design allows designers to create unique visual effects while maintaining the modular truss structure.
Bolt Connection System
The bolt-connected structure provides:
Easy transportation;
Simple installation;
Reusable components;
Flexible project modification.
This makes it suitable for temporary event structures and customized entertainment applications.
Special Shape Fabrication
Besides standard straight sections, BS400 can be customized into:
Four-way corner structures;
Curved sections;
Multi-angle structures;
Special geometric frameworks.
Structural Components
Component
Description
Main Chords
50mm aluminum round tubes forming the main structural frame
BS400 curved truss is mainly used for customized lighting structures, bar installations, entertainment venues and special-shaped aluminum frameworks.
2. Can BS400 truss be manufactured into curved shapes?
Yes. BS400 can be customized into curved sections, corner structures and irregular shapes according to project design requirements.
3. What is the size of BS400 curved truss?
The standard BS400 profile is 400mm × 400mm, using 50mm aluminum round tube main chords.
4. What connection system does BS400 curved truss use?
BS400 curved truss uses a bolt-connected system, allowing easy assembly, dismantling and transportation.
5. Can BS400 custom truss be used outdoors?
Some BS400 custom structures can be used outdoors, but outdoor applications require consideration of environmental loads, wind conditions and engineering requirements.
Design Notice
The drawings represent standard BS400 curved and customized aluminum truss concepts.
Actual production dimensions, connection details and structural requirements should be confirmed according to each project application.
BS400 provides a flexible solution for professional lighting designers, entertainment venues and customized aluminum structural applications.
