The DragonStage 1m Folding Aluminum Concert Stage Barricade is a modular crowd-control barrier designed for front-of-stage audience separation at concerts, festivals, and live events.
Manufactured from 6061-T6 aluminum alloy with 2mm aluminum sheeting, each standard section measures 1.0m wide × 1.2m deep × 1.2m high and folds to approximately 1.0 × 1.2 × 0.13m for transportation and storage.
Available in straight and access-gate configurations, with natural aluminum and black finish options, the system features quick-lock connections and a rear step for security staff.
Product Information
| Item | Specification |
| Brand | DragonStage |
| Model | B1 / B2 |
| Product Type | Folding Aluminum Stage Barricade |
| Section Width | 1,000mm / 3.28ft |
| Overall Depth | 1,200mm / 3.94ft |
| Overall Height | 1,200mm / 3.94ft |
| Unfolded Size | 1.0 × 1.2 × 1.2m |
| Folded Size | Approx. 1.0 × 1.2 × 0.13m |
| Material | Aluminum Alloy 6061-T6 |
| Aluminum Sheet Thickness | 2mm |
| Connection Method | Quick Lock |
| Reference Unit Weight | Approx. 28kg / 61.7lb |
| Listed Packing Volume | Approx. 0.18m³ / pc |
| Features | Foldable Structure / Rear Security Step |
| Finish Options | Natural Aluminum / Black |
| Configurations | Straight Section / Access Gate Section |
| Applications | Concerts, Festivals, Shows, Indoor & Outdoor Events |
| Packing | Individual Bubble Wrap or Carton |
| Customization | Available |
Factory Price Aluminum Stage Crowd Barricade Security Fence Barrier Gate Access Control Barricade
Description
| Model Number | B1/B2 |
| Brand Name | Dragon Stage |
| Place of Origin | China (Mainland) |
| China (Mainland) | Foshan,Guangdong |
| Size:LxWxH | 1m x1.2mx1.2m/foldable size:1mx1.2mx0.13m |
| Material | Aluminium Alloy 6061-T6 |
| Connecting way | Quick lock |
| Advantage | 1. security staff stair;
2. fodable,save volume;
3. aluminium material, lightweight. |
| Application | Concert, Festival, Shows, Indoor&Outdoor event etc. |
| Usage | Outdoor Security |
| Weight/Volume | 28kg/pcs; 0.18cbm/pcs |
| Packing | one pcs in one packages. bubble film or cartons |
| Payment Term | T/T or wester union |
| Delivery Time | 7-15days after deposit |
Factory Price Aluminum Stage Crowd Barricade Security Fence Barrier
Gate Access Control Barricade
Video
Available Product Options
| Configuration | Finish |
| Straight Stage Barricade | Natural Aluminum |
| Straight Stage Barricade | Black |
| Access Gate Barricade | Natural Aluminum |
| Access Gate Barricade | Black |
The gate configuration provides an access option within a planned barricade line. Gate opening dimensions, operation, and hardware details should be confirmed before ordering.
Product Description
The DragonStage Folding Aluminum Stage Barricade is designed for event organizers, concert-production companies, and rental businesses that need a modular audience barrier system in front of temporary stages.
Unlike ordinary lightweight pedestrian barriers, this product uses a deeper folding structure with a rear working area for security personnel.
Each standard section has a nominal width of 1m, allowing multiple sections to be connected into a continuous barricade line.
The quick-lock connection system provides the interface between adjacent sections, while the foldable design helps reduce the space required for transportation and storage.
DragonStage offers both straight barricade sections and access-gate options for different event layouts.
For other crowd-control configurations, explore Typical Aluminum Barrier Systems.
Designed for Front-of-Stage Crowd Management
At concerts and festivals, the area between the audience and the stage must be organized according to the event's crowd-management plan.
A stage barricade provides a physical boundary between the audience-facing area and the working space for event personnel.
Typical uses include:
Concert audience boundaries
Front-of-stage separation
Festival crowd-management layouts
Security working areas
Temporary event access points
Indoor performance venues
Outdoor entertainment events
The final barricade arrangement must account for expected audience behavior, venue conditions, staff access, and the intended operating procedures.
Rear Security Staff Step
The original product design includes a rear step for security staff.
This feature allows authorized personnel to use a designated elevated position behind the audience-facing barrier.
For concert organizers, the security-side arrangement is an important difference between a stage barricade and a conventional pedestrian fence.
The step should be used only as intended by the final product design. Its allowable load and use conditions must be confirmed from the applicable product specifications.
Foldable Design for Transport and Storage
One of the practical advantages of this system is its folding structure.
The standard section measures approximately:
Unfolded: 1.0 × 1.2 × 1.2m
Folded: 1.0 × 1.2 × 0.13m
After an event, the section can be folded to reduce its storage depth.
For rental companies handling multiple barricade sections, this can make warehouse organization and transport planning easier.
The published reference packing volume is approximately 0.18m³ per section, although final packing dimensions may vary by configuration.
Quick-Lock Modular Connections
The barricade uses a quick-lock connection system.
This allows compatible individual sections to be connected into a longer barricade line.
For example, a planned straight run may use multiple standard 1m sections together with any required access-gate sections.
The exact connection geometry and compatibility must be checked when combining the product with barricades from another series or manufacturer.
All connecting components should be correctly engaged before the system is placed into service.
Straight Barricade and Access Gate Options
Different events require different arrangements of audience barriers.
A continuous straight section may be useful where the objective is to define an audience boundary.
An access-gate section can be incorporated where authorized personnel need an entry or exit point within the layout.
Because the product is modular, the number of straight and gate sections can be selected according to the required barricade-line arrangement.
The access-gate section should not automatically be treated as a certified emergency-exit gate. Any required emergency-access or evacuation function must be separately established for the installation.
6061-T6 Aluminum Construction
The current product specification lists 6061-T6 aluminum alloy and 2mm aluminum sheet thickness.
Aluminum construction is useful for temporary event equipment because individual sections can be transported and handled as part of a reusable rental inventory.
The reference unit weight for this product is approximately 28kg per section.
The exact weight may depend on the selected configuration and accessories, particularly where gate hardware or different components are used.
Natural Aluminum or Black Finish
DragonStage offers this product in natural aluminum and black finish options.
Natural aluminum provides a visible metallic appearance.
Black is often preferred for concert and stage environments where the barricade should visually blend with dark production equipment.
The finish should be specified when ordering so the supplied sections match the intended event appearance.
Planning a Complete Barricade Line
When purchasing individual barricades, customers should first establish the required overall layout.
For example, the total run length may involve a combination of:
Straight barricade sections
Access-gate sections
Required turns or changes in direction
Connections between sections
Clearances for event personnel
Other event-specific access arrangements
A layout drawing is helpful when a barricade line contains multiple access points or changes in direction.
The actual quantity and final placement of sections should be confirmed against the event's crowd-management plan rather than calculated from the nominal 1m section width alone.
Main Features
Standard 1m-wide barricade section
1.2m overall height
1.2m overall depth
Folded depth approximately 130mm
6061-T6 aluminum alloy
2mm aluminum sheeting
Quick-lock modular connections
Rear step for security personnel
Straight and access-gate configurations
Natural aluminum and black finish options
Reference unit weight approximately 28kg
Suitable for temporary concert and festival barricade layouts
Reusable folding structure
Important Technical Note
The published product information confirms the standard dimensions, aluminum material, quick-lock connection, foldable construction, rear security step, product options, and reference packing details.
However, it does not establish a verified horizontal crowd-load capacity, maximum permissible crowd pressure, certified impact resistance, or project-specific approval.
For public-event installations, the final barricade configuration must be assessed against the intended crowd-management plan, site conditions, connecting components, and any applicable project requirements.
For further information about the limits of general product specifications and project verification, see Safety Standards & Engineering Constraints.
FAQ
What is the standard size of this aluminum stage barricade?
The standard unfolded dimensions are 1.0m wide × 1.2m deep × 1.2m high.
How small is the barricade when folded?
The published folded size is approximately 1.0 × 1.2 × 0.13m, making the folded structure considerably shallower than the assembled barricade.
How much does one barricade weigh?
The current product lists approximately 28kg per section. The actual weight should be confirmed for the selected straight or gate version.
What material is used?
The product specification lists 6061-T6 aluminum alloy with 2mm aluminum sheeting.
What connection method does the barricade use?
The standard connection method is Quick Lock, allowing compatible barricade sections to be connected into a line.
Does the barricade have a step for security personnel?
Yes. The original product description identifies a rear security staff step.
Is an access-gate version available?
Yes. The listed options include both straight and access-gate barricade configurations.
Can I order black barricades?
Yes. Both natural aluminum and black finish options are listed.
Is this suitable for outdoor concerts?
The product is marketed for indoor and outdoor events. Its actual suitability depends on the complete barricade configuration, ground conditions, expected crowd use, and event-management requirements.
Can these barricades connect to another brand?
Compatibility is not guaranteed by nominal dimensions alone. The quick-lock connection details must be checked before combining different systems.
How many barricades are needed for a concert?
The number depends on the required total length, access-gate positions, changes in direction, and the final event layout. A drawing can help establish the component quantities.
What information is required for a quotation?
Please provide the required number of straight and gate sections, preferred finish, intended event application, delivery destination, and any special connection or layout requirements.
Why Choose DragonStage
DragonStage manufactures and supplies aluminum event barricades, modular stages, truss systems, and related event equipment.
For rental companies and event organizers, a suitable barricade system should be considered in terms of more than individual panel price.
Connection compatibility, foldable storage, available gate sections, finish options, and replacement components all affect how practical the system will be across repeated event projects.
DragonStage can supply standard barricade sections and discuss customized configurations according to the customer's actual event requirements.
Request a Quotation
Please send us:
Required barricade quantity
Straight or access-gate sections
Natural aluminum or black finish
Intended event application
Barricade-line drawing, if available
Any compatibility requirements
Delivery location
DragonStage can then confirm the selected components, packing details, and quotation.
