6.72x4.89m Red Modular Event Stage with 7.7x4.4m Rear Box Truss Gantry
50 Reviews
The DragonStage 6.72x4.89m modular event stage combines a 0.6m-high red stage platform with a 7.7m-wide, 4.4m-high rear box truss gantry. The open-top configuration provides a raised performance area and a separate overhead truss frame for event backdrop and production applications. Suitable for concerts, school performances, ceremonies, and indoor events, with final accessories and rigging requirements confirmed according to the project.
To be confirmed from the production specifications
Accessories
Confirm according to the final package
udes a 4.0m internal opening height, as marked on the drawing.
This type of rear frame can be considered for event backdrops, banners, lighting positions, or other production arrangements, provided the intended equipment and attachment loads are checked against the actual truss configuration.
This stage and rear truss combination may be considered for:
Indoor concerts and live performances
School and university stage events
Corporate presentations and ceremonies
Community celebrations
Small and medium-sized event productions
Promotional shows and temporary performance areas
The open-top arrangement may be useful where a full roof structure is not required. Outdoor use must be assessed separately according to the actual site and weather conditions.
Stage and Gantry Positioning
The illustrated gantry is wider than the stage platform.
The gantry has a 6,900mm internal opening, compared with the stage width of 6,716mm. This provides a nominal difference of 184mm between the two dimensions.
If the stage is positioned between the truss towers, the actual side clearances, platform edges, base plates, and installation tolerances need to be checked before finalizing the layout.
The illustration does not establish whether the stage and truss have any structural connection. Their final positioning and support arrangements should be defined in the production drawings.
Modular Supply and Configuration Options
DragonStage can discuss different stage and truss configurations according to the customer's event requirements.
When preparing a complete package, customers should confirm whether they also require stage stairs, stage skirting, lighting fixtures, LED display equipment, banners, or other accessories.
These items are not established as included components by the supplied drawing and should be specified separately.
The dimensions above are taken from the supplied drawing. The drawing does not provide verified stage load capacity, allowable truss suspension loads, wind resistance, ballast or anchoring requirements, or engineering approval.
The suitability of the stage and gantry for particular equipment, audience use, and installation conditions must be confirmed using the final component specifications and project-specific structural verification.
FAQ
1. What is the size of the stage platform?
The stage measures 6.716m wide × 4.892m deep, with a height of 0.6m. Its footprint is approximately 32.85m².
2. What are the dimensions of the rear gantry truss?
The gantry has an overall width of 7.7m and an overall height of 4.4m. The drawing indicates an internal opening of 6.9m wide × 4.0m high.
3. Does this stage include a roof?
No roof is shown in this configuration. It consists of a raised stage platform and a rear portal-style truss frame.
4. Can lighting fixtures or an LED screen be installed on the rear truss?
The gantry may be considered for event-production equipment, but its allowable suspended load has not been provided. Equipment weights, attachment points, load distribution, and the complete support arrangement must be verified before installation.
5. Are stairs included with the stage?
Stairs are not shown in the supplied drawing. The required stair configuration should be confirmed when preparing the complete stage package.
6. Are the stage and rear truss connected together?
The drawing shows them as separate structural elements. It does not establish a structural connection between them. Their final positions, connections, and support arrangements should be confirmed before production.
7. Can the stage size or gantry dimensions be changed?
Different dimensions and arrangements can be discussed according to the event requirements. Changes may require different stage modules, truss components, connection details, and structural verification.
Why Choose DragonStage
DragonStage manufactures and supplies modular stage and truss products for temporary event applications.
For customers purchasing a complete stage and gantry combination, coordinating the platform dimensions, truss opening, component connections, and required accessories helps reduce configuration mistakes and makes the final quotation more practical.
Request a Quotation
Please send us your required stage dimensions, stage height, truss size, event location, and intended equipment arrangement.
If lighting fixtures, LED screens, banners, or other equipment will be attached to the gantry, please provide their dimensions, weights, and proposed mounting positions so the configuration can be reviewed before quotation.
