11x6x7m Covered Aluminum Concert Roof Truss System with Twin 2m PA Speaker Wings

packing weight:1830kg

packing volume:16cbm

Product Information

Product Description

The DragonStage 11x6x7m Covered Concert Roof Truss System is a complete temporary event-production structure designed around three coordinated areas:

• the main covered stage roof

• the central modular performance platform

• two independent side PA speaker wings

The main roof structure measures:

11m Wide × 6m Deep × 7m High

approximately:

36.1ft × 19.7ft × 23.0ft

Two additional 2m / 6.56ft speaker wings extend from the main structure toward separate outer towers.

This creates a six-tower layout that separates the central performance roof from the two side sound-support positions.

For other event-roof configurations, see Roof Truss.

11m Wide Covered Main Stage Roof

The central structure provides a nominal main width of:

11m / 36.1ft

This width refers to the primary roof frame and does not include the side speaker wings.

Compared with a smaller 10m-wide roof, the additional stage width provides more space for:

• wider performer layouts

• larger band setups

• scenic elements

• stage lighting

• presentation equipment

• event-production zones

The actual clear performance width depends on tower positions and the final stage layout.

6m Roof Depth

The main structure has a nominal depth of:

6m / 19.7ft

This deeper configuration gives the roof more front-to-back coverage than smaller compact stage systems.

The roof framework shown includes multiple transverse members extending between the main truss lines.

The final usable covered depth depends on the canopy geometry, truss positions, and the approved production drawing.

7m Overall Height

The main structure is specified at approximately:

7m / 23ft overall height

This creates overhead space for the pitched roof framework and production equipment.

The 7m dimension should not automatically be interpreted as:

• clear stage height

• line-array hanging height

• lighting working height

• usable internal truss height

These dimensions should be confirmed from the detailed assembly drawing.

Blue Pitched Roof Canopy

Unlike the previous open-frame configuration, this product image clearly shows a blue canopy covering the pitched roof.

The roof cover follows the sloping geometry of the main roof structure.

The final canopy specification should confirm:

• material

• fabric weight

• color

• attachment method

• fire-performance requirement

• waterproof properties

• tensioning arrangement

The image confirms the visual roof covering, but not its complete technical specification.

Twin 2m PA Speaker Wings

Each side of the main roof includes a nominal:

2m / 6.56ft speaker wing

connecting the primary structure to an independent outer tower.

These side positions can be used when planning suitable:

• line-array speaker systems

• PA equipment

• side sound support

• selected production equipment

For related audio-support structures, see Speaker & Line Array Truss.

Why Use Separate Speaker Towers?

A dedicated sound-support position keeps the speaker system outside the main stage opening.

This can help separate:

Main Performance Area

Performers, instruments, stage lighting, scenic elements, and presentation equipment.

Side Audio Areas

Line arrays, PA equipment, and associated sound-production components.

This layout can be more practical than placing every suspended element inside the central roof frame.

The final speaker arrangement must still be based on the actual cabinet weight, array configuration, suspension method, and verified support capacity.

Six-Tower Layout

The illustrated structure uses:

4 Main Roof Towers

supporting the central covered roof.

2 Side Speaker Towers

supporting the left and right PA wings.

This six-tower arrangement is one of the key characteristics of the product.

It should not be confused with a standard four-tower roof system where all lighting and sound equipment must be integrated into the central roof frame.

Approximate Overall Width Including Side Wings

The confirmed main roof width is:

11m

with:

2m speaker wing on each side

A simple nominal layout calculation gives:

11m + 2m + 2m = approximately 15m

or approximately:

49.2ft

across the roof and wing direction.

However, 15m should be treated only as an approximate structural-layout width, not a confirmed outside footprint.

The final total width also depends on:

• tower dimensions

• bases

• outriggers

• wing connection geometry

• final tower spacing

The installation footprint should therefore be taken from the finished drawing.

Matching Modular Stage Platform

The illustrated configuration includes a raised modular stage underneath the roof.

Visible stage features include:

• black deck surface

• modular support structure

• rear guardrails

• side guardrails

• two access stair positions

The stage dimensions have not been supplied.

For that reason, the platform should be selected separately according to the required event capacity and performance layout.

Related systems can be found under Stage Platform.

Suitable for Concert and Festival Use

This configuration can be considered for:

• concerts

• music festivals

• community performances

• cultural events

• church concerts

• school performances

• corporate entertainment

• touring productions

• temporary outdoor stages

• rental-company stage inventory

Its larger 11×6m covered area makes it more suitable for productions that need more stage depth or width than a compact small-event roof.

For related applications, see Concert Event.

Main Features

• Main structure 11 × 6 × 7m

• Approx. 36.1 × 19.7 × 23ft

• Pitched aluminum roof-truss configuration

• Blue roof canopy shown

• Four main roof towers

• Two side speaker towers

• Six tower positions in total

• Twin 2m / 6.56ft PA wings

• Matching modular stage shown

• Rear and side guardrails shown

• Two stair access positions

• Dedicated side sound-support areas

• Suitable for concerts and festivals

• Custom dimensions available

Important Technical Note

The information confirmed from the supplied image and dimensions includes:

• main frame width: 11m

• main frame depth: 6m

• main frame height: 7m

• two 2m speaker wings

• four main roof towers

• two additional side towers

• pitched roof canopy

• illustrated modular stage with guardrails and stairs

The current information does not establish:

• truss section size

• aluminum alloy

• main tube dimensions

• connection system

• roof canopy specification

• roof load

• allowable lighting load

• speaker hanging load

• wind resistance

• ballast

• anchoring

• foundation requirements

• stage dimensions

• stage load

• project-specific engineering approval

These details should be confirmed before manufacture and installation.

FAQ

What is the size of the main roof system?

The main frame measures approximately 11m wide × 6m deep × 7m high, or 36.1 × 19.7 × 23ft.

How wide is each speaker wing?

Each side wing is approximately 2m / 6.56ft.

Are the speaker wings included in the 11m main width?

No. The 11m dimension refers to the main roof frame. The speaker wings extend outward beyond it.

What is the approximate total width including both wings?

The nominal structural layout is approximately 15m before tower bases, outriggers, and other installation clearances are considered.

How many towers are used?

The illustrated system uses six towers: four main roof towers and two speaker towers.

Does the system include a roof canopy?

The supplied image clearly shows a blue pitched roof canopy. Final fabric specifications should be confirmed before quotation.

Can line-array speakers be installed on the side wings?

The wing structures are intended as separate PA support positions, but actual speaker weight, array configuration, suspension method, and allowable loads require verification.

Is the stage included?

A modular stage is shown, but its dimensions and component specification have not been supplied. It should therefore be confirmed as part of the final package.

Does the illustrated stage include guardrails?

Yes. Guardrails are shown along the rear and side edges.

How many stairs are shown?

Two stair positions are visible in the supplied configuration.

Can this system be used outdoors?

It can be configured for outdoor event use, but wind exposure, canopy loads, support conditions, anchoring or ballast and project-specific verification are required.

Can the dimensions be customized?

Yes. Roof size, stage dimensions, overall height, and speaker-wing configurations can be discussed according to the project.

Why Choose DragonStage

DragonStage manufactures modular aluminum roof truss, stage and speaker-support systems for concert and event applications.

This configuration brings three normally separate requirements together:

covered stage roof + modular performance platform + twin speaker wings

For event companies, planning these elements together makes it easier to coordinate the stage footprint, tower positions, sound system, access and overall site layout before manufacture.

Request a Quotation

Please provide:

• required roof width and depth

• required overall height

• stage dimensions and height

• speaker model and quantity

• individual speaker / array weight

• preferred hanging height

• lighting equipment requirements

• roof-cover requirements

• indoor or outdoor use

• event location

• stair and guardrail requirements

DragonStage can then confirm the final stage-roof and PA-wing configuration.
