Section:Square400x500mm
Inclined tube: 25x2.0mm
Main tube:50x3.0mm
Braces:50x2.0mm
Material: Aluminum 6061-T6

Section:Square500x500mm
Inclined tube: 25x2.0mm
Main tube:50x3.0mm
Braces:50x2.0mm
Material: Aluminum 6061-T6
This heavy-duty 500x500mm bolt aluminum square truss is the ultimate foundation for outdoor concert stages and large-scale events. Engineered for maximum structural stability, this aluminum truss system provides the high-load capacity needed to support massive lighting rigs and heavy audio arrays safely in any environment.

Section:Square400x400mm
Inclined tube: 25x2.0mm
Main tube:50x3.0mm
Braces:50x2.0mm
Material: Aluminum 6061-T6

Outdoor Speaker Aluminum Stand Line Array Gentry Truss Tower 5m High

The 4m × 6m DragonStage Channel Tent is a customized aluminum A-frame tent designed to create a covered passage between backstage or stage-side preparation areas and the main stage. It can be installed inside an opening intentionally reserved within a larger Ringlock structure, helping protect performers, staff, costumes and equipment from rain while providing a more private and clearly defined access route.

The 4m × 6m Built-In Hybrid Ringlock FOH Booth is a compact technical workspace designed for Front of House control, DJ operation, and event control-cabin use. It combines a Ringlock-integrated support concept with an aluminum roof frame, modular plank floor, roof tarpaulin, side curtains, and front/rear enclosure panels, making it suitable for integration inside larger event structures.

4m × 4m multi-level FOH control tower combining a modular Ringlock main structure with an aluminum single-slope roof frame. Maximum height is 7m, with a 6m low-side roof height and 7m high-side roof height. The package includes working platforms, aluminum ladders, roof and canopy tarpaulins, curtain enclosure, auxiliary base structure and related stabilization components for concert and event production

6m × 4m hybrid FOH control booth combining a modular Ringlock main structure with an aluminum single-slope roof frame, modular working platform, curtain enclosure, roof tarpaulin, and access ladder. Designed for concert, festival, and temporary event technical-control applications

2m × 6m hybrid FOH control booth combining a modular Ringlock main structure with an aluminum gable roof frame, 2m eave height, 3m central ridge height, modular working platform, weather curtains and steel stair access for concert and event technical control applications.

Steel Ringlock Truss Round Pipe Segment Beam

Compact 2m × 2m FOH control booth combining a modular Ringlock main frame with an aluminum A-frame roof and roof tarpaulin. The booth has 2m side/eave height and a 3m central ridge height, providing a small covered technical workspace for concerts, festivals and temporary event production.

6m × 6m aluminum flat roof truss system with a 4m front height and 6m rear height, using a four-tower modular support configuration for concerts, lighting rigs, stage productions, and temporary event applications. Custom manufactured by DragonStage.

The 4m × 6m Hybrid Ringlock FOH Control Booth is a customized Front of House structure for concert, festival, live-event, and production-control applications.

The main booth structure is built from a modular Ringlock system, while the pitched roof uses a separate aluminum frame. This combination allows the booth body, working floor, enclosure, and roof components to be supplied as one coordinated temporary-event package.

The confirmed dimensions for this configuration are:

• Width: 4m
• Depth: 6m
• Overall structure height: 3m
• Side / eave height: 2m
• Roof ridge height: 2.5m

The structure also includes roof tarpaulins, side and rear/front curtain panels, aluminum roof beams, platform planks, diagonal bracing, and steel ballast-pipe components according to the supplied BOQ.

DragonStage supplies other modular temporary structures through our Ringlock Structure System product range.

The 4m × 4m Multi-Level Hybrid Ringlock FOH Control Tower is a customized Front of House control structure designed for concerts, festivals, live productions, and other temporary event applications.

This product combines a Ringlock main tower structure with an aluminum roof frame and weather-cover system, creating a compact but elevated technical-control tower for audio, lighting, video, or show-operation use.

The confirmed project dimensions are:

• Width: 4m
• Depth: 4m
• Overall maximum height: 7m
• Side height: 6m
• Roof low point: 6m
• Roof high point: 7m

This makes it a sloped-roof hybrid FOH tower, with the roof rising from the lower side to the higher side.

According to the supplied BOQ, the structure includes the Ringlock main body, internal planks, ladder-access components, aluminum roof beams, side-wall curtain posts, roof tarpaulin, side and front/back curtains, ballast-pipe components, and a lower auxiliary base structure.

DragonStage manufactures customized temporary event structures through our Ringlock Structure System and Custom Stage Production services.

U Frame Lighting Truss Aluminium U Frame Lighting Frame

Professional Rental LED Screen Pad Block Mounting System - Precision Adjustable Spacing Bracket with Locking Nut for Stage Truss Video Wall Installation

Professional LED Screen Truss Steel Wire Rope Buckle Bundling Tool - Heavy-Duty Auxiliary Tightening Strap with Secure Locking Buckle for Stage Display Installation

The 24ft × 24ft Flat Roof Aluminum Truss System is a customized four-tower event truss structure with a 20ft tower height, designed for temporary stages, lighting installations, concerts, performances, corporate events, and other event-production applications.

The system uses four vertical aluminum truss towers supporting a square flat-roof truss framework. Internal cross truss members divide the overhead area into multiple rigging zones, allowing the roof framework to be configured around the actual lighting and event-equipment layout.

The drawing also shows a tower lifting arrangement with sleeve blocks, allowing the assembled upper truss grid to be positioned on the vertical towers as part of the installation process.

DragonStage manufactures flat roof systems in different dimensions and configurations. See more products in our Typical Flat Roof Truss System range.

the ringlock tower high 6m, 2m deep and 2m wide.

The 8.3m Heavy Duty Layher Truss Support Tower System is a professional, high-capacity rigging structure designed for outdoor concerts, large events, and festival stages. Engineered with a stable 6m × 2m base footprint and high-strength modular components, this system provides a secure overhead rigging solution for line array audio speakers, LED screens, and heavy lighting rigs. Its fast pin-and-wedge assembly ensures quick setup and maximum stability for demanding stage applications.

20m×18m Ringlock stage + 12m high aluminum roof truss system with 2×10m side wings. Ultimate hybrid concert setup for LED walls & line arrays.

the total length is 5m, 2.6m deep and max height 1.2m and minum height 0.3m, aluminum sheet anti slip deck.

Aluminum Double Width Portable Scaffolding 6.14m

The 24m × 24m x6m Aluminum Truss Tent Structure is a customized outdoor covering solution designed for terraces, resorts, beach areas, hospitality spaces, and temporary event applications.

Based on the customer's requirements, this structure uses a 400mm aluminum screw truss system with a pyramid roof design, supported by 10 aluminum truss columns and covered with a white waterproof PVC tarpaulin.

The open-span design provides a large covered outdoor area while maintaining a clean architectural appearance suitable for outdoor events and commercial spaces.

DragonStage manufactures customized Aluminum Truss structures according to customer dimensions, application requirements, and project conditions.

Professional 12U and 16U flight case rack cabinet for mixers, amplifiers and event audio equipment. DragonStage provides customized rack cases for concerts, touring productions and professional events.

This customized large tunnel event structure combines a 24m wide × 18m deep × 15m high tunnel aluminum truss system with a 21.96m × 14.4m × 2m high stage platform.

The upper structure uses multiple large curved aluminum truss arches connected by longitudinal truss sections, creating a wide-span architectural framework above the event area. The complete system can be supplied together with the elevated stage platform as a customized package for stadium events, ceremonies, concerts, festivals, and other large temporary productions.

The dimensions shown here come from an actual customer quotation requirement rather than a standard catalogue size.

DragonStage manufactures customized Roof Truss systems in different dimensions and configurations according to project requirements.

2 Ton Chain Block 1 Ton Manual Chain Block Lifting Chain Block Chain Hoist for Event Truss System

This customized 12m × 10m Ringlock concert stage system combines a 2m-high main stage, a 2m × 6m runway, four access stairs, three-sided Ringlock wall structures, approximately 4m-wide LED support areas on both sides, and a customized 400 × 400mm aluminum truss package above the stage.For other modular configurations, see our Ringlock Stage System

This 14m × 10m Ringlock concert stage system is a customized large-event stage package combining a steel Ringlock stage platform, aluminum peak roof truss, 6m-wide side structures for LED screens, and dedicated structures for line array suspension.

The main performance platform measures 14m × 10m, with a requested stage height of up to 2m. Ringlock scaffolding is also used to build the surrounding support structures up to approximately 10m high, matching the main stage and the 6m-wide wings on both sides.

Instead of purchasing the stage platform, roof truss, LED supports, and sound-support structures separately, customers can order them as one coordinated event-stage package from DragonTruss.

For other modular stage configurations, see our Ringlock Stage System.

2m × 2m modular Ringlock audience viewing platform originally configured for socially distanced concert seating areas. The system features a 0.2m-high aluminum pallet platform, three-sided double-rail guardrails, an open rear entrance, adjustable steel base jacks, and a front-facing position for event or sponsor posters.

20m wide × 14m deep × 10m high custom curved roof truss system featuring six main support towers and two 2m-wide side wings for line array systems with manual hoists. Designed as a modular aluminum truss structure for concerts, festivals, live productions, and other large event applications.

This custom mobile DJ table is designed for a customer who needed one standalone DJ workstation rather than a complete stage system.

The table uses the same basic manufacturing logic as a professional aluminum stage platform: an aluminum frame, flat black working surface, rigid support structure, and replaceable modular components. However, instead of stage legs standing directly on the floor, this version is fitted with four lockable caster wheels so the complete table can be moved short distances inside a club without dismantling the DJ equipment.

The finished size is 2200mm wide × 800mm deep × 900mm high, providing a large working surface for multiple DJ players, a mixer, laptop, or controller.

For other aluminum platform products manufactured using similar structural principles, see our Aluminum Stage range.

DragonTruss manufactures integrated stage and truss systems combining modular aluminum stage platforms with aluminum truss structures for event applications.

This customized project includes a 9.76m x 9.76m Quick Stage main platform, a 2.44m wide x 3.66m long runway stage, and a 400x400mm spigot truss gantry structure with a 10m width and 5m height.

The system integrates a quick assembly stage platform with a modular truss framework, providing a complete structure solution for event decoration, lighting installation, and potential LED screen applications.

For customized stage structures combining platforms, truss systems, and accessories, DragonTruss provides complete Custom Stage Production services according to project requirements.

This custom black F34 curved truss arch structure was produced based on a customer's requested configuration, combining curved F34 truss elements, F32/F34 box corners, straight truss sections, and outdoor base plates.

Unlike standard straight truss products, curved truss structures require additional manufacturing coordination, including curve fabrication, connector alignment, component matching, and surface finishing. The final structure demonstrates DragonTruss's capability in producing customized aluminum truss solutions beyond standard configurations.

For projects requiring special shapes, customized layouts, or integrated stage structures, DragonTruss also provides Custom Stage Production services based on project requirements.

Section:Square600x760mm
Inclined tube: 25x2.0mm
Main tube:50x4.0mm
Braces:50x2.0mm

Section:Square670x1010mm
Inelined tube: 30x2.0mm
Main tube:50x5.0mm
Braces:50x3.0mm

the spigot truss sectional sizes are 830mm wide and 630mm deep. the main tube is 50x4mm or 60x5mm.

U-frame Truss And Dolly, it is custom for 4  and 5 Robots.

 U Frame Drop U-Torm Modular Truss Black Modular Drop Arm Moving Head Light Truss U Frame Truss Pipe Truss

The Square Box Truss F34 Circle Corner 2 Ways 90 Degree is characterized by its square shape and the incorporation of circular corners at two ends, forming a 90-degree angle. This design not only adds an aesthetic appeal to the structure but also enhances its structural integrity. The circular corners help distribute the load more evenly, reducing stress concentrations and improving the overall stability of the truss.

BOOM Arm truss For K34/k44 Truss Aluminium Arm 500cm 600cm Optional High Quality Stage Accessories

Fit for 48-51mm truss

Material: Aluminum

2.8m long, 50kg and max loading 10 tons

custom Aluminum Top Sections with Steel Wheels for Beam Truss 520x760mm are a popular choice for motor hoisting system due to their durability, strength, and versatility.

this is a African Outdoor Event Lighting Truss Frame used for rental, it is sizes are 10m long, 8m deep and 6m high.

This Aluminum Concert Professional Light Truss 18x12x9m seems is a high-quality and durable solution for concert and event lighting setups. The dimensions are suitable for large-scale productions, and the material is known for its strength and lightweight properties. This truss system appears is a reliable option for professional use in the entertainment industry.

the total sizes are 18m long, 8m wide and 8m high, the beam is 500x600mm spigot truss and pillar is 350x350mm.

this custom 12m long and 6m beam truss is 389x389mm or 400x400mm

1.Professional welders and engineers to ensure high quality
2.Portable and convenient
3.Easy to assemble

Square Round Aluminum Church Audio Lighting Truss 10m
