When shopping for moving beam lights, you will often see product names such as 5R Beam, 7R Beam, or 15R Moving Head. Many buyers assume that "5R" refers to the wattage of the fixture, but this is not correct.
In reality, 5R originally refers to a specific discharge lamp model, and over time it has become a common industry term used to describe a class of compact moving beam lights.
What Does 5R Mean?
The term 5R originally comes from the Philips MSD Platinum 5R discharge lamp.
This high-intensity short-arc lamp became extremely popular in stage lighting because it produced a bright, narrow beam while consuming relatively low power.
Many manufacturers began designing moving head fixtures around this lamp, and the name "5R Beam" gradually became an industry standard.
Typical specifications include:
Lamp type: Philips MSD Platinum 5R
Lamp power: approximately 189W
Color temperature: approximately 8000K
Typical lamp life: around 3,000 hours
Is 5R the Same as 200W?
Not exactly.
Many products are marketed as:
5R 200W Beam Moving Head
The "200W" refers to the approximate fixture power or the lamp class rather than the exact lamp consumption.
For example:
Philips MSD Platinum 5R has a nominal power of about 189W.
Manufacturers often round this to 200W for easier product classification.
Why Is 5R So Popular?
5R moving beam lights became popular because they offer:
High beam intensity
Long projection distance
Compact fixture size
Relatively low power consumption
Fast beam movement
Excellent aerial effects
These advantages made them widely used for:
Concerts
Nightclubs
Wedding stages
Touring productions
Outdoor events
Television shows
5R vs. 7R vs. 15R
As lighting technology evolved, larger discharge lamps were introduced.
Lamp Type
Approximate Power
Typical Application
5R
189–200W
Small and medium venues
7R
230W
Medium venues
10R
280W
Professional productions
15R
330–350W
Large concerts and arenas
17R
350W+
Stadium and outdoor events
Higher-R fixtures generally produce:
Brighter beams
Longer throw distances
Larger optical systems
Higher purchase costs
Are 5R Fixtures Still Used Today?
Yes.
Although LED moving head technology has advanced rapidly, 5R beam lights remain popular, especially for:
Rental companies
Wedding productions
DJs
Clubs
Small concert stages
Budget-conscious event organizers
They continue to provide excellent beam effects at an affordable cost.
Are LED Beam Lights Replacing 5R Lamps?
Many modern manufacturers now offer LED moving beam lights that eliminate the need for discharge lamps.
Compared with traditional 5R fixtures:
LED Beam Lights
Longer lifespan
Lower maintenance
Instant on/off
Lower energy consumption
No lamp replacement
5R Discharge Beam Lights
Extremely concentrated beam
Excellent long-distance projection
Mature and proven technology
Lower initial purchase cost in many markets
Both technologies continue to be used depending on application and budget.
Conclusion
The term 5R originally referred to the Philips MSD Platinum 5R discharge lamp, but today it has become a widely recognized industry term describing compact moving beam fixtures in the 200W class. While newer LED technologies are becoming increasingly common, 5R beam lights remain a practical and cost-effective solution for many stage lighting applications.
Frequently Asked Questions
Is 5R a wattage rating?
No. 5R refers to a lamp model rather than the exact wattage.
Can I replace a 5R lamp with a 7R lamp?
Generally, no. Different lamps have different dimensions, power requirements, and optical designs. Always follow the fixture manufacturer's recommendations.
Is LED better than 5R?
It depends on the application. LED fixtures offer lower maintenance and energy consumption, while traditional 5R fixtures are still valued for their powerful beam effects and affordability.
