Dragonstage
packing weight:1850kg
packing volume:25cbm
| Item | Specification(squre truss) | Qty | ||||||
| length | main tube(mm) | size(mm) | ||||||
| 15.00 m Beam(front) | 2 sets | 3.00 m | 50×4.0 | CS520×760 | 10pcs | |||
| 2.00 m | 50×4.0 | CS520×760 | 0pcs | |||||
| 1.00 m | 50×4.0 | CS520×760 | 0pcs | |||||
| 12.00 m Beam(side) | 2 sets | 3.00 m | 50×4.0 | CS520×760 | 8pcs | |||
| 2.00 m | 50×4.0 | CS520×760 | 0pcs | |||||
| 1.00 m | 50×4.0 | CS520×760 | 0pcs | |||||
| 8.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS389×389 | 8pcs | |||
| 2.00 m | 50×3.0 | CS389×389 | 4pcs | |||||
| 1.00 m | 50×3.0 | CS389×389 | 0pcs | |||||
| beam cube | 6 faces | CS520×760 | 0pcs | |||||
| Frame Tower | Spigot Sleeve Block L | 4pcs | ||||||
| Steel Base L | 4pcs | |||||||
| Top Section L | 4pcs | |||||||
| Manual hoist,BA05 2Tons | 4pcs | |||||||
| Spigot Hinge Section,Height 1m | 4pcs | |||||||
| Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
| Long outrigger | 16pcs | |||||||
This Professional 15m x 12m Aluminum Lighting Truss System provides a massive, high-capacity rigging solution for major event productions. Designed with a four-tower ground support configuration, this system is engineered to safely elevate extensive lighting, audio, and visual equipment.
Expansive Dimensions: Offers a large 15-meter length and 12-meter depth footprint with a professional 9-meter height, providing maximum overhead clearance for diverse stage setups.
High-Stability Ground Support: The structure utilizes four heavy-duty vertical towers equipped with wide-span outriggers and stable base plates to ensure structural integrity and balance under heavy loads.
Modular Box Truss Construction: Built using high-quality aluminum truss segments, the system is designed for ease of transport and efficient assembly at any venue.
Versatile Rigging Frame: The rectangular perimeter provides a continuous overhead rigging point, ideal for complex lighting designs, large-scale banners, or supporting secondary stage elements.
Industrial Durability: Constructed from premium 6061-T6 aluminum alloy, offering an exceptional strength-to-weight ratio and a professional finish resistant to environmental wear.
For marquee festival productions and stadium-scale concerts, the overhead structure is the most critical asset on the site. The 15x12x9m Professional Aluminum Ground Support Lighting Truss System by DragonStage is an elite engineering solution providing a massive 180 square meters of covered performance area. Featuring a commanding 9-meter vertical clearance, this system is specifically designed for high-capacity rigging of lighting, audio, and large-format LED screens. Utilizing a traditional heavy-duty bolt connection and professional ground support towers, this system offers the structural stability and technical flexibility required to meet the most demanding touring riders.
The primary challenge of a 15-meter horizontal span is managing structural deflection—the natural tendency of aluminum to bow under its own weight and rigged technical loads. DragonStage solves this by utilizing 6061-T8 aluminum alloy, which is solution heat-treated and cold-worked to achieve a significantly higher yield strength and hardness than standard T6 alloys. Another major concern for 9-meter high outdoor structures is lateral wind stability; our ground support system features reinforced tower bases with extended outriggers and heavy-duty leveling jacks, ensuring a secure center of gravity. To prevent water pooling on such a large roof span, the system includes a high-tension, pitched PVC canopy that ensures immediate water runoff during unpredictable weather.
The 15x12x9m system is manufactured from aerospace-grade 6061-T8 aluminum alloy. This specialized material is the premier choice for long-span rigging because it provides superior rigidity and resistance to structural "creep" over years of heavy professional use (Source:https://www.dragontruss.com/Aluminum-Truss-System-pd413987768.html).
The system features a professional 4-tower or 6-tower ground support configuration. This allows the entire 15x12m grid to be fully rigged with lighting, audio line arrays, and cabling at waist height before being safely hoisted to its 9-meter apex. According to international safety standards for temporary structures, the use of a heavy-duty bolt-connection system provides massive surface contact at each joint, ensuring the most rigid structural union possible for heavy-duty applications (Source:https://www.plasa.org).
To provide a complete venue environment, this trussing is designed for seamless integration with our modular aluminum stage platforms. These decks feature 18mm anti-slip surfaces and high load-bearing capacities, creating a stable foundation that matches the professional grade of the overhead rig (Source:https://www.dragontruss.com/Aluminum-Stage-Platform-pd463987768.html).
Q: Why use 6061-T8 alloy for a 15m span?A: At a 15-meter span, structural rigidity is paramount. The T8 temper is harder and more resistant to deformation than standard T6, ensuring the truss remains perfectly level under heavy rigging.
Q: Can this 9-meter structure support heavy LED video walls?A: Yes. The 6061-T8 heavy-duty box truss is specifically engineered for high-capacity rigging. For your specific panel weight, please contact our engineers for a verified load-bearing report.
Q: Is the PVC canopy fire-retardant?A: Absolutely. Our canopies are made from 850g/m² PVC that is waterproof, UV-resistant, and meets international B1/M2 fire-retardant safety standards.
Q: What type of hoists do I need for a 15x12m grid?A: Given the weight of a 15-meter span and the potential rigging load, we strongly recommend using synchronized 1-ton electric chain hoists for a safe and level lift.
Ensure your next stadium-scale production is built on a foundation of elite engineering and industrial safety. Contact DragonStage’s engineering team today for a custom quote on the 15x12x9m Professional Ground Support Lighting Truss System. Download our technical specifications and start planning your most successful concert season yet.
