packing weight: 1600kg
packing volume: 13cbm
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 10.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 6pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 2pcs |
| 10.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 6pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 2pcs |
| 6.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| beam cube | Spigotcube 289x289 | 0pcs |
| Frame Tower | Spigot Sleeve Block S | 4pcs |
| Steel Base S | 4pcs |
| Top Section S | 4pcs |
| Manual hoist,BA05 2Tons | 4pcs |
| Spigot Hinge Section,Height 1m | 4pcs |
| Fibre sling,BA04,2 tons 3m | 4pcs |
| Long outrigger | 16pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | 2 sets | 1.00 m | 50×3.0 | CS289×289 | 2pcs |
| 10.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 3pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 1pcs |
| 5.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 2.20 m | 50×3.0 | CS289×289 | 4pcs |
| 5.20 m Ladder truss | 8 sets | 3.00 m | 50×3.0 | CL30,289*50 | 8pcs |
| 2.00 m | 50×3.0 | CL30,289*50 | 0pcs |
| 2.20 m | 50×3.0 | CL30,289*50 | 8pcs |
| Roof Components |
| roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs |
| roof conner 5 ways, use for roof beam truss | CS289×289 | 0pcs |
| Connect plate with clamp | 2pcs |
| Single clamp | 16pcs |
| Double clamp | 8pcs |
| roof canopy material:pvc, Blue Colour or customized. | 177.36 | 1pcs |
Professional Aluminum Custom 10x10x7m Concert Outdoor Lighting Truss System
1. Introduction
In the competitive world of live event production, the "sweet spot" for medium-sized outdoor festivals and corporate shows is often a 100-square-meter footprint. The 10x10x7m Aluminum Custom Concert Outdoor Lighting Truss from DragonStage is engineered to provide this exact versatility. Balancing a 10-meter clear span with a 7-meter vertical clearance, this system offers the professional "big stage" look while remaining agile enough for rapid deployment. For event organizers and rental companies, the challenge lies in finding a rig that is sturdy enough to carry heavy lighting plots but portable enough for regional touring. This custom system addresses those needs with precision-engineered aluminum components designed for high-impact performance.
2. Challenges & Solutions
One of the primary frustrations for outdoor stage builders is the risk of structural instability on soft or uneven surfaces. A 10x10m roof acts as a significant wind sail; without proper anchoring, safety becomes a liability. DragonStage solves this through a heavy-duty ground-support system featuring reinforced sleeve blocks and long-arm outriggers that distribute weight effectively. Another common pain point is the time-consuming process of rigging lights at height. Our solution utilizes a tower-and-hoist system that allows the entire lighting grid to be assembled and wired at ground level before being raised to the 7-meter peak, significantly reducing labor costs and enhancing technician safety.
3. Key Features & Benefits
The backbone of this 10x10x7m system is its 6082-T6 aluminum alloy construction, a material renowned for its high yield strength and natural resistance to environmental oxidation (Source:https://www.dragontruss.com/Aluminum-Truss-System-pd413987768.html). This ensures that even after years of exposure to rain and sun, the truss maintains its structural integrity and professional aesthetic.
The roof system is topped with a heavy-duty, fire-retardant PVC canopy that is tensioned to ensure immediate water runoff. According to international event safety standards, a properly tensioned canopy is essential to prevent the accumulation of "water pockets" that can lead to structural collapse (Source:https://www.lsionline.com).
Furthermore, the 10x10m rig is fully compatible with our modular aluminum stage platforms. These platforms feature height-adjustable legs and anti-slip surfaces, providing a stable foundation for performers that aligns perfectly with the overhead lighting grid (Source:https://www.dragontruss.com/Aluminum-Stage-Platform-pd463987768.html). This synergy creates a "plug-and-play" environment where lighting, sound, and staging work in total harmony.
4. FAQ Section
Q: What is the maximum weight the 10m span can support?A: Depending on the truss profile selected (e.g., 290mm or 390mm), the system can typically support a distributed load of 500kg to 800kg across the main span.
Q: Can this truss be used without the roof canopy?A: Yes. The aluminum framework is a standalone structural system. The canopy is modular and can be removed for indoor events or clear-weather outdoor shows.
Q: How do you raise the roof grid to 7 meters?A: The system is designed for use with manual hand-winches or electric chain hoists, which are attached to the top of the four pillars.
Q: Is it difficult to transport?A: No. Despite its large assembled size, the system breaks down into modular truss sections and compact corner blocks that are easily loaded into a standard box truck.
5. Strong Call to Action (CTA)
Ensure your next outdoor production is built on a foundation of safety and professional engineering. Contact DragonStage’s engineering team for a custom quote on the 10x10x7m aluminum lighting truss. Download our technical specifications and start planning your most successful concert season yet.
