Outdoor Roof Truss for Beam Light And Stage Machine Eventos Venezuela

5 0 Reviews

14x12x8m can change into 10x10x8m

Price: ￥ 93470 - 106910


Size:	beam 400x400 pillar 300x300 beam 500x600 pillar 350x350
Availability:



Inquire

Brand:
Dragon Stage

Product Description

packing weight: 2600kg

packing volume:25cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
14.00 m Beam(front)	3 sets	3.00 m	50×3.0	BS400×400	12pcs
		2.00 m	50×3.0	BS400×400	3pcs
		1.00 m	50×3.0	BS400×400	0pcs
12.00 m Beam(side)	2 sets	3.00 m	50×3.0	BS400×400	8pcs
		2.00 m	50×3.0	BS400×400	0pcs
		1.00 m	50×3.0	BS400×400	0pcs
7.00 m Pillar	6 sets	3.00 m	50×3.0	BS300×300	12pcs
		2.00 m	50×3.0	BS300×300	0pcs
		1.00 m	50×3.0	BS300×300	6pcs
beam cube	cube 400x400				0pcs
Frame Tower	Bolt Truss Sleeve Block S				6pcs
	Steel Base S				6pcs
	Top Section S				6pcs
	Manual hoist,BA05 2Tons				6pcs
	Spigot Hinge Section,Height 1m				6pcs
	Fibre sling,BA04,2 tons 3m				6pcs
	Long outrigger				24pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
Roof Pillar	3 sets	1.40 m	50×3.0	BS300×300	3pcs
12.00 m Top Beam	1 sets	3.00 m	50×3.0	BS300×300	4pcs
		2.00 m	50×3.0	BS300×300	0pcs
		1.00 m	50×3.0	BS300×300	0pcs
7.20 m Oblique Beam	6 sets	3.00 m	50×3.0	BS300×300	6pcs
		2.00 m	50×3.0	BS300×300	6pcs
		2.20 m	50×3.0	BS300×300	6pcs
7.20 m Ladder truss	8 sets	3.00 m	50×3.0	BL30,300*50	8pcs
		2.00 m	50×3.0	BL30,300*50	8pcs
		2.20 m	50×3.0	BL30,300*50	8pcs
Roof Components		roof conner 4 ways, use for roof beam truss		BS400×400	2pcs
		roof conner 5 ways, use for roof beam truss		BS400×400	1pcs
		Connect plate with clamp			3pcs
		Single clamp			16pcs
		Double clamp			12pcs
		roof canopy material:pvc, Blue Colour or customized.		274.96	1pcs
Truss Accessory		Conical coupler & Safrty clip & pin			whole set

packing weight: 3100KG

packing volume: 32CBM

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
14.00 m Beam(front)	3 sets	3.00 m	50×3.0	BS500×600	12pcs
		2.00 m	50×3.0	BS500×600	3pcs
		1.00 m	50×3.0	BS500×600	0pcs
12.00 m Beam(side)	2 sets	3.00 m	50×3.0	BS500×600	8pcs
		2.00 m	50×3.0	BS500×600	0pcs
		1.00 m	50×3.0	BS500×600	0pcs
7.00 m Pillar	6 sets	3.00 m	50x3.0	BS350×350	12pcs
		2.00 m	50x3.0	BS350×350	0pcs
		1.00 m	50x3.0	BS350×350	6pcs
beam cube	cube 500x600				0pcs
Frame Tower	Bolt Truss Sleeve Block M				6pcs
	Steel Base M				6pcs
	Top Section M				6pcs
	Manual hoist,BA05 2Tons				6pcs
	Spigot Hinge Section,Height 1m				6pcs
	Fibre sling,BA04,2 tons 3m				6pcs
	Long outrigger				24pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
Roof Pillar	3 sets	1.40 m	50×3.0	BS400×400	3pcs
12.00 m Top Beam	1 sets	3.00 m	50×3.0	BS400×400	4pcs
		2.00 m	50×3.0	BS400×400	0pcs
		1.00 m	50×3.0	BS400×400	0pcs
7.20 m Oblique Beam	6 sets	3.00 m	50×3.0	BS400×400	6pcs
		2.00 m	50×3.0	BS400×400	6pcs
		2.20 m	50×3.0	BS400×400	6pcs
7.20 m Ladder truss	8 sets	3.00 m	50×3.0	BL30,300*50	8pcs
		2.00 m	50×3.0	BL30,300*50	8pcs
		2.20 m	50×3.0	BL30,300*50	8pcs
Roof Components		roof conner 4 ways, use for roof beam truss		BS400×400	2pcs
		roof conner 5 ways, use for roof beam truss		BS400×400	1pcs
		Connect plate with clamp			3pcs
		Single clamp			16pcs
		Double clamp			12pcs
		roof canopy material:pvc, Blue Colour or customized.		274.96	1pcs

Heavy-Duty Outdoor Roof Truss for Beam Lights and Stage Productions

1. Introduction

Large-scale outdoor events, particularly in demanding climates like Venezuela, require more than just a frame; they require a robust, weather-defying engineering solution. The Outdoor Roof Truss for Beam Lights and Stage (Machine Eventos) by DragonStage is designed to provide a massive overhead rigging capacity for heavy-duty beam lights and automated fixtures. This 12x10m system offers the structural height and stability needed for professional concert lighting, ensuring that high-intensity beams have the vertical clearance required for maximum visual impact. Built for reliability in the "Machine Eventos" tradition, this structure is the preferred choice for organizers who refuse to compromise on safety or production value.

2. Challenges & Solutions

Event professionals often struggle with the weight limitations of standard trusses when deploying modern, heavy beam lights and LED moving heads. A primary challenge is managing the center-span deflection that occurs over a 12-meter width. DragonStage solves this by utilizing high-density 290mm or 390mm square trussing that maintains a flat, rigid profile even under significant weight loads. Furthermore, in regions prone to sudden tropical downpours or high winds, water pooling on a roof can lead to structural failure. Our solution features a pitch-roof design with tensioned PVC that facilitates immediate water runoff, combined with heavy-duty tower bases and outriggers that ensure the structure remains anchored and level on varied terrain.

3. Key Features & Benefits

The "Machine Eventos" system is manufactured from 6082-T6 aluminum, the highest standard for load-bearing temporary structures, offering exceptional resistance to both physical stress and environmental corrosion (Source:https://www.dragontruss.com/Aluminum-Truss-System-pd413987768.html). This ensures that the rig remains a safe, long-term investment for rental companies and venue owners alike.

The system utilizes a sophisticated sleeve block and hinge tower arrangement. This allows the entire roof grid to be assembled at waist height, where technicians can safely mount beam lights and cabling, before being hoisted to its final working height via manual or electric chain hoists. According to rigging authority guidelines, the use of sleeve blocks significantly reduces the risk of tower failure by distributing vertical forces more evenly (Source:https://www.lsionline.com).

To complement the overhead rig, this system is designed for seamless integration with our modular aluminum stage platforms. These platforms provide a high-friction, waterproof surface that supports the dynamic movement of performers and heavy stage machinery (Source:https://www.dragontruss.com/Aluminum-Stage-Platform-pd463987768.html).

4. FAQ Section

Q: What is the maximum wind speed this roof system can withstand?A: When properly guy-wired and ballasted, the system is designed to withstand winds up to 60-70 km/h, though the canopy should be removed if higher winds are forecasted.

Q: Can I use this for hanging line array speakers?A: Yes. By adding optional cantilever wings to the side towers, the structure can support both your lighting grid and audio arrays.

Q: Is the PVC canopy fire-retardant?A: Absolutely. The canopy is made from 850g/m² PVC that is waterproof, UV-protected, and meets international B1/M2 fire safety standards.

Q: What type of connections does this system use?A: This model uses high-precision conical couplers (spigots) for fast, vibration-resistant assembly, making it ideal for the frequent setups required in touring.

5. Strong Call to Action (CTA)

Empower your next event with a structural rig built for the world stage. Contact DragonStage’s engineering team for a customized configuration of our Outdoor Roof Truss system. Download our load-bearing charts and technical drawings to see how the "Machine Eventos" solution can elevate your production standards.
