packing weight: 1550kg
packing volume: 11cbm
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 6.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 4pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| 5.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 2pcs |
| 2.00 m | 50×3.0 | CS289×289 | 2pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| 5.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4pcs |
| 2.00 m | 50×3.0 | CS289×289 | 4pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| Frame Tower | Spigot Sleeve Block S | 4pcs |
| Steel Base S | 4pcs |
| Top Section S | 4pcs |
| Manual hoist,BA05 2Tons | 4pcs |
| Spigot Hinge Section,Height 1m | 4pcs |
| Fibre sling,BA04,2 tons 3m | 4pcs |
| Long outrigger | 16pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | 2 sets | .60 m | 50×3.0 | CS289×289 | 2pcs |
| 5.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 1pcs |
| 2.00 m | 50×3.0 | CS289×289 | 1pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| 3.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 0pcs |
| 2.00 m | 50×3.0 | CS289×289 | 4pcs |
| 1.20 m | 50×3.0 | CS289×289 | 4pcs |
| 3.20 m Ladder truss | 4 sets | 3.00 m | 50×3.0 | CL30,289*50 | 0pcs |
| 2.00 m | 50×3.0 | CL30,289*50 | 4pcs |
| 1.20 m | 50×3.0 | CL30,289*50 | 4pcs |
| Roof Components |
| roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs |
| roof conner 5 ways, use for roof beam truss | CS289×289 | 0pcs |
| Connect plate with clamp | 2pcs |
| Single clamp | 8pcs |
| Double clamp | 8pcs |
| roof canopy material:pvc, Blue Colour or customized. | 72.56 | 1pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 2.00 m Wings Beam | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 0pcs |
| 2.00 m | 50×3.0 | CS289×289 | 2pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| 5.00 m Wings Pillar | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 2pcs |
| 2.00 m | 50×3.0 | CS289×289 | 2pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| Wings Tower | Spigot Sleeve Block S | 2pcs |
| Steel Base S | 2pcs |
| Top Section S | 2pcs |
| Manual hoist,BA05 2Tons | 2pcs |
| Spigot Hinge Section,Height 1m | 2pcs |
| Fibre sling,BA04,2 tons 3m | 2pcs |
| Long outrigger | 8pcs |
| Truss Accessory |
| Conical coupler & Safrty clip & pin | whole
set |
Professional 6x5x6m Square Runway Outdoor Lighting Truss System with 1.5m Wings
1. Introduction
High-end fashion shows and outdoor brand activations require a specialized structural aesthetic that highlights the movement on the runway while providing massive rigging flexibility. The 6x5x6m Square Runway Outdoor Lighting Truss System by DragonStage is engineered specifically for these precision environments. Featuring a unique 2-wing design with 1.5m widths, this system allows for the seamless integration of audio and video components outside the main performance corridor. For event producers, the challenge is creating a 6-meter high vertical "frame" that provides perfect overhead lighting angles without cluttering the runway's visual lines—a challenge this modular aluminum system solves with clinical efficiency.
2. Challenges & Solutions
One of the primary difficulties in outdoor runway production is the "sightline vs. sound" conflict. Large speaker stacks on the ground can block audience views, while hanging them directly over the runway can be a safety risk. DragonStage solves this with 1.5m wide side wings, providing dedicated outrigger points for line arrays that keep the audio clear of the visual path. Additionally, outdoor runways are prone to unpredictable weather; rain on a sleek runway surface is a major safety hazard for models. Our 6x5x6m system includes a high-tension PVC canopy and a pitched roof design that ensures immediate water runoff, keeping the "catwalk" dry and the lighting electronics protected throughout the show.
3. Key Features & Benefits
The structure is fabricated from aerospace-grade 6082-T6 aluminum alloy, offering a high strength-to-weight ratio that is essential for structures with cantilevered wings (Source:https://www.dragontruss.com/Aluminum-Truss-System-pd413987768.html). This ensures that the 6-meter towers maintain verticality even when supporting offset loads from heavy LED side-panels or speakers.
The system features a modular ground-support design, allowing the lighting grid to be pre-rigged at floor level. This is particularly beneficial for fashion shows, where lighting focus must be exact; technicians can adjust "barn doors" and angles before hoisting the rig to its 6-meter peak. According to industry safety standards for fashion and event structures, the use of reinforced sleeve blocks is critical for maintaining stability at height (Source:https://www.lsionline.com).
Furthermore, this lighting truss is designed to be perfectly compatible with our customizable aluminum stage platforms, which can be configured into a 5-meter or longer runway with professional anti-slip surfacing (Source:https://www.dragontruss.com/Aluminum-Stage-Platform-pd463987768.html). This integrated approach ensures that the lighting grid and the runway floor are perfectly aligned for symmetrical production.
4. FAQ Section
Q: Are the 1.5m wings strong enough for LED screens?A: Yes. The wings are reinforced to support distributed loads, making them ideal for vertical LED banners or brand signage.
Q: Can this system be set up on a parking lot?A: Absolutely. Our tower bases include heavy-duty leveling jacks that can compensate for the slope of asphalt or uneven pavement.
Q: Is the PVC canopy fire-retardant?A: Yes, the canopy meets international B1/M2 fire safety standards, making it safe for use with high-heat theatrical lighting.
Q: What is the benefit of the "Square" design?A: The square truss profile provides superior resistance to "twisting" forces compared to triangular trussing, which is vital when using side-wings for audio.
5. Strong Call to Action (CTA)
Create a world-class runway experience with a structural rig built for style and safety. Contact DragonStage’s engineering team for a custom configuration of the 6x5x6m Runway Lighting Truss System. Download our technical drawings today and start planning your next high-impact fashion event.
