packing weight:1020kg
packing volume:8cbm
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 8.00 m Beam(front) | sets | 3.00 m | 50×3.0 | CS289×289 | pcs |
| 2.00 m | 50×3.0 | CS289×289 | pcs |
| 1.00 m | 50×3.0 | CS289×289 | pcs |
| 4.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | pcs |
| 2.00 m | 50×3.0 | CS289×289 | 4 pcs |
| 1.00 m | 50×3.0 | CS289×289 | pcs |
| 5.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4 pcs |
| 2.00 m | 50×3.0 | CS289×289 | pcs |
| 1.00 m | 50×3.0 | CS289×289 | 4 pcs |
| Tower | Spigot Sleeve Block S | 4 pcs |
| Steel Base S | 4 pcs |
| Top Section S | 4 pcs |
| Manual hoist,BA05 2Tons | 4 pcs |
| Spigot Hinge Section,Height 1m | 4 pcs |
| Fibre sling,BA04,2 tons 3m | 4 pcs |
| Long outrigger | 16 pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | sets | .80 m | 50×3.0 | CS289×289 | pcs |
| 4.00 m Top Beam | sets | 3.00 m | 50×3.0 | CS289×289 | pcs |
| 2.00 m | 50×3.0 | CS289×289 | 2 pcs |
| 1.00 m | 50×3.0 | CS289×289 | pcs |
| 10.00 m Arch Beam | 3 sets | 3.00 m | 50×3.0 | CS289×289 | 6 pcs |
| 2.00 m | 50×3.0 | CS289×289 | 6 pcs |
| .00 m | 50×3.0 | CS289×289 | pcs |
| 10.00 m Ladder truss | sets | 3.00 m | 50×3.0 | CL30,289*50 | pcs |
| 2.00 m | 50×3.0 | CL30,289*50 | pcs |
| .00 m | 50×3.0 | CL30,289*50 | pcs |
| Roof Components |
| spigot multi cube, use for roof beam truss | CS289×289 | pcs |
| Connect plate with clamp | pcs |
| Single clamp | pcs |
| Double clamp | 12 pcs |
| roof canopy material:pvc, Blue Colour or customized. | 101.28 | 1 pcs |
Our Curved Roof Assembly Aluminum Alloy Mobile Stage Truss is an industry-standard solution for event professionals who need a blend of aesthetics and structural integrity. With an 8m length, 4m depth, and 5m height, this system provides a commanding presence for mid-sized outdoor performances, corporate events, and exhibitions.
Key Features
Superior Material: Constructed from high-strength aluminum alloy (typically 6061-T6), offering a high strength-to-weight ratio that is corrosion-resistant and ideal for outdoor use.
Advanced Arch Design: The curved roof structure is not only visually striking but also engineered for efficient water runoff and enhanced load-bearing capacity for lighting and sound equipment.
Modular Portability: Designed for rapid deployment, the system uses quick-connection hardware (spigot or bolt) to ensure stability while remaining easy to transport and assemble.
Stability & Safety: Features heavy-duty base plates and a tower-based support system to ensure a secure foundation on various outdoor terrains.
Technical Specifications
| Feature | Detail |
|---|
| Dimensions | 8m (L) x 4m (D) x 5m (H) |
| Material | Aluminum Alloy 6061-T6 / 6082-T6 |
| Main Tube | Typically 50mm x 3mm |
| Structure Type | Modular Space Frame / Arched Roof |
| Finish | Polished Aluminum or Custom Matte Black |
| Applications | Concerts, Festivals, Trade Shows, Outdoor Weddings |
