3752-BS300 Five Main Tube Round Tube Bolt-Connected Aluminum Truss Design for Indoor Lighting Structures
Drawing File Reference
Drawing Index
3752
Related Drawing Files
The above drawing represents the BS300 five main tube round tube bolt-connected aluminum truss component designed for indoor lighting structures, bar equipment structures and decorative installations.
The drawing index is used as a reference for locating related CAD drawings and production records.
Drawing Information
Item
Details
Drawing Index
3752
Drawing Series
BS300 Five Main Tube Round Tube Bolt-Connected Truss
Structure Type
Custom Length Aluminum Truss Component
Application
Indoor Lighting Structure / Bar Equipment Structure
Cross Section
Width 300mm × Height 300mm
Main Tube
50mm Aluminum Round Tube
Available Length
0.25m
Environment
Indoor Application
Material
Aluminum Alloy
Connection System
Bolt Connection
Drawing Type
2D CAD Drawing
Design Purpose
Indoor Lighting Structure Component
3752-BS300 Five Main Tube Bolt Truss Design for Indoor Bar and Lighting Structures
Introduction
This drawing archive presents the 3752-BS300 five main tube round tube bolt-connected aluminum truss component developed for indoor lighting structures, bar equipment installations and decorative event applications.
The drawing is indexed under reference 3752, and the related drawing file represents a compact-length configuration manufactured according to the same BS300 structural concept.
Different from standard long-span lighting truss sections, this BS300 configuration is designed as a short structural component. The five main tube design provides additional structural members within the truss frame, making it suitable for indoor applications requiring compact dimensions and customized installation layouts.
The BS300 series can be integrated into customized indoor lighting systems, bar structures and decorative frameworks according to project requirements.
Design Overview
The 3752-BS300 adopts a modular bolt-connected round tube structure.
Compared with fixed welded structures, bolt-connected truss components provide advantages in:
Transportation efficiency;
Storage convenience;
Flexible assembly;
Customized structural configuration.
The five main tube configuration provides a different structural arrangement compared with conventional four-main-tube truss designs.
This type of compact truss component is commonly selected when installation space is limited and a stronger visual or structural connection point is required.
The connection method is an important factor when selecting temporary structure components. Different connection systems, such as spigot connection, bolt connection and plate connection, are selected according to application requirements.
More information about truss connection methods can be found in:
For indoor lighting and entertainment structures, individual truss components are only one part of the complete installation system.
The final configuration depends on:
Equipment weight;
Installation position;
Supporting method;
Ceiling or building structure conditions;
Required safety factors.
Indoor applications usually have fewer environmental influences compared with outdoor structures, but equipment loading and fixing methods remain important considerations.
Material selection also affects structural performance. Aluminum alloy is widely used in event structures because of its lightweight characteristics, corrosion resistance and clean appearance.
For future purchasing applications, this drawing archive can be connected with:
BS300 Five Main Tube Round Tube Bolt Truss
Possible product configuration:
BS300 × 0.25m Five Main Tube Bolt Truss
The drawing archive demonstrates Dragon Stage's custom design capability, while product pages provide purchasing information and specifications.
FAQ
1. What is the BS300 five main tube bolt truss mainly used for?
The BS300 five main tube bolt truss is mainly designed for indoor lighting structures, bar equipment frameworks and decorative installations.
2. Why is this BS300 configuration only 0.25m long?
The short length is designed for compact connection sections, customized layouts and indoor structures where standard long truss sections are not suitable.
3. What is the difference between this BS300 and standard lighting truss?
This BS300 configuration uses a round tube bolt-connected structure with five main tubes and is designed mainly for indoor customized structures rather than conventional long-span lighting grids.
4. Can BS300 truss lengths be customized?
Yes. The length and configuration can be customized according to project dimensions, equipment requirements and installation conditions.
5. Can Dragon Stage provide complete indoor lighting structure solutions?
Yes. Dragon Stage can provide customized solutions including truss selection, structural configuration and manufacturing support.
Design Notice
The drawings shown in this archive are provided for reference purposes to demonstrate Dragon Stage's custom design capability.
Final structural design should be confirmed according to actual project requirements, loading conditions, installation environment and applicable safety requirements.
