The 24m × 24m x6m Aluminum Truss Tent Structure is a customized outdoor covering solution designed for terraces, resorts, beach areas, hospitality spaces, and temporary event applications.

Based on the customer's requirements, this structure uses a 400mm aluminum screw truss system with a pyramid roof design, supported by 10 aluminum truss columns and covered with a white waterproof PVC tarpaulin.

The open-span design provides a large covered outdoor area while maintaining a clean architectural appearance suitable for outdoor events and commercial spaces.

DragonStage manufactures customized Aluminum Truss structures according to customer dimensions, application requirements, and project conditions.

This customized large tunnel event structure combines a 24m wide × 18m deep × 15m high tunnel aluminum truss system with a 21.96m × 14.4m × 2m high stage platform.

The upper structure uses multiple large curved aluminum truss arches connected by longitudinal truss sections, creating a wide-span architectural framework above the event area. The complete system can be supplied together with the elevated stage platform as a customized package for stadium events, ceremonies, concerts, festivals, and other large temporary productions.

The dimensions shown here come from an actual customer quotation requirement rather than a standard catalogue size.

DragonStage manufactures customized Roof Truss systems in different dimensions and configurations according to project requirements.

This 14m × 10m Ringlock concert stage system is a customized large-event stage package combining a steel Ringlock stage platform, aluminum peak roof truss, 6m-wide side structures for LED screens, and dedicated structures for line array suspension.

The main performance platform measures 14m × 10m, with a requested stage height of up to 2m. Ringlock scaffolding is also used to build the surrounding support structures up to approximately 10m high, matching the main stage and the 6m-wide wings on both sides.

Instead of purchasing the stage platform, roof truss, LED supports, and sound-support structures separately, customers can order them as one coordinated event-stage package from DragonTruss.

For other modular stage configurations, see our Ringlock Stage System.

2m × 2m modular Ringlock audience viewing platform originally configured for socially distanced concert seating areas. The system features a 0.2m-high aluminum pallet platform, three-sided double-rail guardrails, an open rear entrance, adjustable steel base jacks, and a front-facing position for event or sponsor posters.

This custom mobile DJ table is designed for a customer who needed one standalone DJ workstation rather than a complete stage system.

The table uses the same basic manufacturing logic as a professional aluminum stage platform: an aluminum frame, flat black working surface, rigid support structure, and replaceable modular components. However, instead of stage legs standing directly on the floor, this version is fitted with four lockable caster wheels so the complete table can be moved short distances inside a club without dismantling the DJ equipment.

The finished size is 2200mm wide × 800mm deep × 900mm high, providing a large working surface for multiple DJ players, a mixer, laptop, or controller.

For other aluminum platform products manufactured using similar structural principles, see our Aluminum Stage range.

DragonTruss manufactures integrated stage and truss systems combining modular aluminum stage platforms with aluminum truss structures for event applications.

This customized project includes a 9.76m x 9.76m Quick Stage main platform, a 2.44m wide x 3.66m long runway stage, and a 400x400mm spigot truss gantry structure with a 10m width and 5m height.

The system integrates a quick assembly stage platform with a modular truss framework, providing a complete structure solution for event decoration, lighting installation, and potential LED screen applications.

For customized stage structures combining platforms, truss systems, and accessories, DragonTruss provides complete Custom Stage Production services according to project requirements.

This custom black F34 curved truss arch structure was produced based on a customer's requested configuration, combining curved F34 truss elements, F32/F34 box corners, straight truss sections, and outdoor base plates.

Unlike standard straight truss products, curved truss structures require additional manufacturing coordination, including curve fabrication, connector alignment, component matching, and surface finishing. The final structure demonstrates DragonTruss's capability in producing customized aluminum truss solutions beyond standard configurations.

For projects requiring special shapes, customized layouts, or integrated stage structures, DragonTruss also provides Custom Stage Production services based on project requirements.

BOOM Arm truss For K34/k44 Truss Aluminium Arm 500cm 600cm Optional High Quality Stage Accessories

Fit for 48-51mm truss

Material: Aluminum
