BS300 Round Tube Bolt-Connected Aluminum Truss with Side Connection Plate Customized Length Design

Views: 12     Author: Site Editor     Publish Time: 2026-08-02      Origin: Site

Inquire

facebook sharing button
line sharing button
pinterest sharing button
twitter sharing button
linkedin sharing button
whatsapp sharing button
wechat sharing button
sharethis sharing button
BS300 Round Tube Bolt-Connected Aluminum Truss with Side Connection Plate Customized Length Design

Drawing Name

BS300 Round Tube Bolt-Connected Aluminum Truss with Side Connection Plate Customized Length Design

Drawing Index

  • 3939

  • 4246

  • 4291

Drawing Information

Item

Details

Drawing Series

BS300-SCP

Structure Type

Straight Customized Bolt-Connected Truss

Main Tube

50mm Aluminum Round Tube

Cross Section

300mm × 300mm

Connection System

Bolt Connection + Side Connection Plate

Material

Aluminum Alloy

Environment

Indoor

Application

Exhibition Lighting Structure / Bar Lighting Structure / Decorative Framework

Drawing Type

2D CAD Drawing

Design Purpose

Indoor Lighting and Decorative Structural Component

Product / Drawing Description

BS300 Round Tube Bolt-Connected Aluminum Truss with Side Connection Plate

The BS300-SCP series is a customized straight aluminum bolt-connected truss system designed for indoor lighting structures, exhibition frameworks and decorative installations.

Compared with standard BS300 truss sections, this configuration adds side connection plates to provide additional installation flexibility for special layouts.

The reinforced side plate design allows the truss section to connect with customized structures, supporting frames and decorative components in applications such as:

  • Exhibition halls;

  • Bars and entertainment venues;

  • Indoor lighting systems;

  • Decorative structures.

The system uses a 300mm × 300mm square truss profile with 50mm aluminum round tubes and adopts bolt-connected assembly.

Available Configurations


BS300-SCP-065

Length:

0.65m

Drawing Reference:

4246-BS300(0.65m) Bolt Truss With Side Plate

Application:

Short connecting section for customized indoor lighting structures.


BS300-SCP-076

Length:

0.76m

Drawing Reference:

4291-BS300(0.76m) Bolt Truss

Application:

Compact decorative and lighting framework component.


BS300-SCP-146

Length:

1.46m

Drawing Reference:

4291-BS300(1.46m) Bolt Truss

Application:

Medium-length connection component for exhibition and entertainment structures.


BS300-SCP-210

Length:

2.10m

Drawing Reference:

3939-BS300(2.1m) Bolt Truss With Side Plate

Application:

Main structural section for indoor lighting framework.


BS300-SCP-343

Length:

3.43m

Drawing Reference:

4291-BS300(3.43m) Bolt Truss With Side Plate

Application:

Long-span customized lighting and decorative structure component.

Structural Features

1. BS300 Square Profile

The truss adopts:

  • Width: 300mm

  • Height: 300mm

  • Main tube diameter: 50mm

This size provides a balance between:

  • Visual appearance;

  • Structural stiffness;

  • Installation flexibility.

2. Side Connection Plate Design

The additional side plate provides:

  • Customized connection points;

  • Better compatibility with special structures;

  • Easier integration with exhibition and entertainment frameworks.

This design is commonly used where standard truss connections cannot satisfy the installation requirement.

3. Bolt Connection System

The bolt-connected structure provides:

  • Easy transportation;

  • Convenient assembly;

  • Flexible configuration;

  • Replaceable components.

Compared with welded fixed structures, modular bolt-connected truss systems are more suitable for temporary event structures.

Typical Applications

Exhibition Lighting Structure

The BS300-SCP series can be used for:

  • Exhibition booth lighting frames;

  • Decorative arches;

  • Hanging lighting structures;

  • Display frameworks.

Related:

Exhibition Booth

Bar Lighting Structure

For entertainment venues, this type of truss can be used for:

  • Bar lighting racks;

  • DJ lighting structures;

  • Decorative ceiling frameworks.

Related:

Lighting Truss

Engineering Notes

The final configuration of customized truss structures depends on:

  • Installation method;

  • Equipment loading;

  • Supporting conditions;

  • Span requirements;

  • Environmental conditions.

For indoor applications, structural requirements are generally focused on:

  • Lighting equipment weight;

  • Connection reliability;

  • Installation stability;

  • Visual requirements.

For larger outdoor applications, additional considerations such as wind load and structural analysis are required.

FAQ

1. What is BS300-SCP bolt-connected truss used for?

BS300-SCP is mainly used for indoor lighting structures, exhibition frameworks, bar lighting systems and decorative installations.

2. What is the difference between BS300-SCP and standard BS300 truss?

BS300-SCP adds side connection plates, allowing more flexible connection with customized structures.

3. Can the length of BS300-SCP be customized?

Yes. Length, connection position and additional plates can be customized according to project requirements.

4. Is BS300-SCP suitable for outdoor applications?

The design shown is mainly for indoor applications. Outdoor use requires additional structural evaluation according to environmental conditions.

5. Why choose bolt-connected aluminum truss?

Bolt-connected aluminum truss provides modular assembly, easier transportation and flexible installation compared with permanent welded structures.

Design Notice

The drawings shown in this archive are provided for reference purposes to demonstrate Dragon Stage's custom design capability.

Final structural design should be confirmed according to actual project requirements, loading conditions, installation environment and applicable safety requirements.
