Premium 8x7x5m Custom Outdoor Pitch Roof Truss Structure
1. Introduction: The Need for Professional, Weather-Resistant Stage Coverage
Outdoor concerts, corporate events, and large public gatherings require more than just a stage; they require certified, reliable overhead protection. The DragonStage Custom Outdoor Pitch Roof Truss Structure provides a robust, weather-defying canopy for your event. With external dimensions of 8m (W) x 7m (D) x 5m (H), this system is specifically designed to cover and protect vital performance areas and equipment from unpredictable weather.
Engineered with high-grade aluminum and a classic pitched roof design, this truss structure ensures maximum rainwater runoff and provides dedicated rigging points for professional lighting and audio systems, making it the essential infrastructure for any major outdoor production.
2. Engineering for Reliability and Logistics
Event production logistics face consistent pressure to deploy large structures quickly while maintaining the highest structural safety standards. The choice of truss structure is paramount, especially when anticipating wind and rain.
DragonStage’s solution integrates premium materials and smart design to overcome these challenges.
High-Grade Aluminum: The structure utilizes CS289x289 square truss sections with a main tube size of $\mathbf{50 \times 3.0 \text{mm}}$. This material choice provides exceptional structural strength for heavy-duty rigging while maintaining a manageable overall weight for transport and assembly.
Optimal Rain Protection: The pitch roof design is crucial. Unlike flat roofs, the angled pitch actively sheds water, preventing the dangerous accumulation of rain load which can lead to structural failure during severe weather.
Efficient Transport: Despite its large scale, the system is designed for modular packing, minimizing the cubic volume required for transport and storage, translating directly into reduced logistics costs for event rental companies and touring productions.
3. Core Technical Components and Structural Integrity
The 8x7x5m pitch roof truss system is a complete framework, including all necessary components for secure ground support and overhead rigging.
Vertical and Horizontal Framework
| Component | Specification | Quantity | Purpose |
| Pillars (Legs) | $50 \times 3.0$mm CS289x289 | 4 sets | Provides 5m vertical height support. |
| Main Beam (Front/Back) | $50 \times 3.0$mm CS289x289 | 2 sets (8.00m length) | Defines the main rigging and span of the roof. |
| Side Beam | $50 \times 3.0$mm CS289x289 | 2 sets (7.00m length) | Defines the depth and side-load capacity. |
Dedicated Pitch Roof Assembly
The pitch roof structure is composed of specialized parts to ensure shape and weather resilience:
Oblique Beams and Ladder Trusses form the slopes of the roof, actively supporting the canopy material.
Roof Corners (4 ways) and Connect Plates ensure tight, secure connection points at all peak and corner vertices.
A custom-sized 114.16 PVC canopy is included, providing waterproof covering in Blue or a custom color, tailored precisely to the roof's geometry.
Security and Rigging Hardware
The entire system relies on reliable and proven connection methods, including Single and Double Clamps for accessory attachment (lights, banners), and a secure Spigot Connection mechanism for rapid, high-strength assembly of the main truss segments.
4. Why Choose a Custom Pitch Roof Design?
The pitch roof offers distinct advantages over typical flat or dome designs for mid-to-large-scale outdoor events:
Superior Water Shedding: The angle of the roof prevents water ponding, mitigating the risk of dynamic weight overload during heavy rainfall.
Clear Vertical Rigging: The central peak provides natural elevation, offering greater head clearance and enhanced vertical load capacity for heavy lighting and large video screens.
Aesthetic Appeal: The classic pitched profile is visually strong and professional, framing the stage area effectively for cameras and audiences.
5. Strong Call to Action (CTA)
Secure your next event under a structure built for reliability and designed for performance. The DragonStage 8x7x5m Pitch Roof Truss System is ready to be customized for your exact specifications.
Contact our engineering team today to request a detailed load chart and receive a custom consultation on your specific concert or event requirements.
