| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 30.00 m Beam(front) | 3 sets | 3.00 m | 50×5.0 | CS680×1010 | 30pcs |
| 2.00 m | 50×5.0 | CS680×1010 | 0pcs |
| 1.00 m | 50×5.0 | CS680×1010 | 0pcs |
| 20.00 m Beam(side) | 3 sets | 3.00 m | 50×5.0 | CS680×1010 | 18pcs |
| 2.00 m | 50×5.0 | CS680×1010 | 0pcs |
| 1.00 m | 50×5.0 | CS680×1010 | 6pcs |
| 11.00 m Pillar | 6 sets | 3.00 m | FALSE | CS520×520 | 18pcs |
| 2.00 m | FALSE | CS520×520 | 6pcs |
| 1.00 m | FALSE | CS520×520 | 0pcs |
| beam cube | Spigot cube 680x1010 | 0pcs |
| Frame Tower | Spigot Sleeve Block L | 6pcs |
| Steel Base L | 6pcs |
| Top Section L | 6pcs |
1. Dragon stage brand, Load:1000kg,
2. Chain length:25m,
3. lifting speed:4m/min,
4. 380V-3phrase-50HZ
5. Double brake
6. G100 load chain, meeting 8:1/10:1 safety factor.
7. With 0.5M 4Pin-16A Europe plug
8. waterproof: IP54 | 6pcs |
| 1control 8pcs, with Handle case | 1pcs |
| Spigot Hinge Section,Height 1m | 6pcs |
| Fibre sling,BA04,2 tons 3m | 6pcs |
| Long outrigger | 24pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | 3 sets | 3.00 m | 50×3.0 | CS389×389 | 3pcs |
| 20.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS389×389 | 6pcs |
| 2.00 m | 50×3.0 | CS389×389 | 0pcs |
| 1.00 m | 50×3.0 | CS389×389 | 2pcs |
| 15.20 m Oblique Beam | 6 sets | 3.00 m | 50×3.0 | CS389×389 | 24pcs |
| 2.00 m | 50×3.0 | CS389×389 | 6pcs |
| 1.20 m | 50×3.0 | CS389×389 | 6pcs |
| 15.20 m Ladder truss | 16 sets | 3.00 m | 50×3.0 | CL40,389*50 | 64pcs |
| 2.00 m | 50×3.0 | CL40,389*50 | 16pcs |
| 1.20 m | 50×3.0 | CL40,389*50 | 16pcs |
| Roof Components |
| roof conner 4 ways, use for roof beam truss | CS389×389 | 2pcs |
| roof conner 5 ways, use for roof beam truss | CS389×389 | 1pcs |
| Connect plate with clamp | 3pcs |
| Single clamp | 32pcs |
| Double clamp | 12pcs |
| roof canopy material:pvc, Blue Colour or customized. | 857.36 | 1pcs |
