20x20m Large Span Pyramid Roof Truss System with 3 Long-Span Beams for Layher System

5 0 Reviews

20m×20m heavy-duty aluminum roof truss with 3 long-span beams, designed for a large LED screen, line array & lighting of Layher stage truss system.

Price: ￥ 65165


Availability:



Inquire

Brand:
Dragonstage

Product Description

20x20m Large Span Pyramid Roof Truss System with 3 Long-Span Beams for Layher System (2)

packing weight: 1260kg

packing volume: 18cbm

12.00 m Beam(front)	3 sets	3.00 m	50×3.0	CS389×389	12pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
12.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS389×389	8pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
beam cube	6 faces	CS389×389			6pcs

Roof Pillar	3 sets	1.20 m	50×3.0	CS389×389	3pcs
12.00 m Top Beam	1 sets	3.00 m	50×3.0	CS389×389	4pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
6.20 m Oblique Beam	4 sets	3.00 m	50×3.0	CS389×389	4pcs
		2.00 m	50×3.0	CS389×389	4pcs
		1.20 m	50×3.0	CS389×389	4pcs
6.20 m Ladder truss	10 sets	3.00 m	50×3.0	CL30,289*50	10pcs
		2.00 m	50×3.0	CL30,289*50	10pcs
		1.20 m	50×3.0	CL30,289*50	10pcs
Roof Components	4	roof conner 4 ways, use for roof beam truss		CS389×389	2pcs
	5	roof conner 5 ways, use for roof beam truss		CS389×389	1pcs
	1	Connect plate with clamp		CS389×389	3pcs
		Single clamp			20pcs
		Double clamp			8pcs
		roof canopy material:pvc, Blue Colour or customized.		238.56	1pcs

This professional-grade system is designed with specific dimensions and materials to ensure long-span reliability:

Structure Type: Pyramid Roof Truss System with 3 Long-Span Beams
Application: Mega Concerts, International Festivals, Large Outdoor Event Stages
Dimensions:

Footprint: 20 meters (Width) x 20 meters (Depth)
Coverage: 400 square meters of protected stage area.

Truss Specification:

Main Truss: Square Truss CS389x389
Main Cord Diameter: 50mm x 3.0mm thickness aluminum alloy (Ensuring maximum strength-to-weight ratio).

Roof Canopy: Professional-grade PVC material (Custom colors available, ideal for weather protection and branding).
Load Capacity: Engineered for heavy loads, specifically supporting large line array speaker systems, extensive lighting rigs, and oversized LED screens.

Advanced Engineering and Operational Advantages

The design of this 20x20m system incorporates several professional features that streamline event production logistics:

Layher System Compatibility: A key feature is the system's design for integration with Layher System scaffolding components. This compatibility provides enhanced flexibility for constructing robust support towers and auxiliary structures, allowing producers to adapt quickly to challenging terrains and diverse load requirements.
Three Long-Span Beams: The inclusion of three primary long-span beams provides redundant strength across the 20-meter width, minimizing deflection and maximizing the allowable hanging load (live load) for complex technical production elements.
Pyramid Roof Aesthetics: The iconic Pyramid Roof shape not only offers optimal structural distribution but also presents a high-impact, recognizable profile, creating a powerful focal point for televised broadcasts and high-resolution media.
Modular Heavy-Duty Components: The use of standardized, high-specification square truss sections (CS389x389) ensures component interchangeability and simplifies on-site assembly, teardown, and transportation, directly addressing the logistical challenges of major events.
Weather Protection Envelope: The PVC canopy system is secured to the structure, providing reliable shelter against rain and sun, ensuring the continuous operation and integrity of sensitive electronic and audio-visual equipment.

This 20m x 20m Large Span Pyramid Roof Truss System is the professional choice for producers who refuse to compromise on safety, scale, or structural performance.
