This professional aluminum stage truss roof system is designed for large-scale outdoor concerts, festivals, and events, with a total length of 14m, depth of 30m, and height of 5m. Constructed from high-grade aluminum alloy (typically 6061-T6), it offers a superior strength-to-weight ratio and excellent corrosion resistance for long-term durability.
The modular design features a robust ground support configuration with a pitched roof, ideal for both rain protection and lighting setup. This system provides the structural integrity necessary to safely hang extensive lighting rigs, sound systems, and video displays. It uses a reliable spigot connection system for quick and easy assembly and disassembly, making it highly versatile for touring and various event configurations.
packing weight:3990kg
packing volume:37cbm
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 14.00 m Beam(front) | 4 sets | 3.00 m | 50×3.0 | CS389×389 | 16pcs |
| 2.00 m | 50×3.0 | CS389×389 | 4pcs |
| 1.00 m | 50×3.0 | CS389×389 | 0pcs |
| 30.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS389×389 | 18pcs |
| 2.00 m | 50×3.0 | CS389×389 | 0pcs |
| 1.00 m | 50×3.0 | CS389×389 | 6pcs |
| 4.00 m Pillar | 8 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 8pcs |
| beam cube | 6 faces | CS389×389 | 0pcs |
| Frame Tower | Spigot Sleeve Block S | 8pcs |
| Steel Base S | 8pcs |
| Top Section S | 8pcs |
| Manual hoist,BA05 2Tons | 8pcs |
| Spigot Hinge Section,Height 1m | 8pcs |
| Fibre sling,BA04,2 tons 3m | 8pcs |
| Long outrigger | 32pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | 4 sets | 1.40 m | 50×3.0 | CS289×289 | 4pcs |
| 30.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 9pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 3pcs |
| 7.20 m Oblique Beam | 8 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs |
| 2.00 m | 50×3.0 | CS289×289 | 8pcs |
| 2.20 m | 50×3.0 | CS289×289 | 8pcs |
| 7.20 m Ladder truss | 24 sets | 3.00 m | 50×3.0 | CL30,289*50 | 24pcs |
| 2.00 m | 50×3.0 | CL30,289*50 | 24pcs |
| 2.20 m | 50×3.0 | CL30,289*50 | 24pcs |
| Roof Components | 4 | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs |
| 5 | roof conner 5 ways, use for roof beam truss | CS289×289 | 2pcs |
| 1 | Connect plate with clamp | CS289×289 | 4pcs |
| Single clamp | 48pcs |
| Double clamp | 16pcs |
| roof canopy material:pvc, Blue Colour or customized. | 577.36 | 1pcs |
