Our 15x15m Outdoor Aluminum Stage Truss Roof System is engineered for maximum performance and safety at large-scale outdoor events. Constructed from high-grade, lightweight aluminum alloy (e.g., 6061-T6/6082-T6), this robust ground support structure provides a substantial 225 square meters of covered area with an impressive 6-meter vertical clearance.
Key Features & Benefits:
Robust Construction: The entire framework is built with durable square box truss, ensuring excellent structural integrity and a high load capacity for demanding lighting, sound, and video rigging plots.
Weather Resistant: Designed to withstand unpredictable weather conditions, the system is resistant to rust and corrosion, and a properly installed canopy (not included) ensures excellent water drainage and rain protection.
Modular Design: Our truss system is completely modular, allowing for swift and efficient assembly and disassembly. This versatility reduces logistical complexity and setup time.
Professional Appearance: The clean, industrial design of the aluminum truss adds a professional and visually appealing look to any event, which clients and crowds will appreciate.
packing weight:2480kg
packing volume:30cbm
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 15.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 10pcs |
| 2.00 m | 50×3.0 | CS500×600 | 0pcs |
| 1.00 m | 50×3.0 | CS500×600 | 0pcs |
| 15.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS500×600 | 10pcs |
| 2.00 m | 50×3.0 | CS500×600 | 0pcs |
| 1.00 m | 50×3.0 | CS500×600 | 0pcs |
| 5.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS389×389 | 4pcs |
| 2.00 m | 50×3.0 | CS389×389 | 4pcs |
| 1.00 m | 50×3.0 | CS389×389 | 0pcs |
| beam cube | 6 faces | CS500×600 | 0pcs |
| Frame Tower | Spigot Sleeve Block M | 4pcs |
| Steel Base M | 4pcs |
| Top Section M | 4pcs |
| Manual hoist,BA05 2Tons | 4pcs |
| Spigot Hinge Section,Height 1m | 4pcs |
| Fibre sling,BA04,2 tons 3m | 4pcs |
| Long outrigger | 16pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | 2 sets | 1.50 m | 50×3.0 | CS289×289 | 2pcs |
| 15.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 5pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| 7.70 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4pcs |
| 2.00 m | 50×3.0 | CS289×289 | 4pcs |
| 2.70 m | 50×3.0 | CS289×289 | 4pcs |
| 7.70 m Ladder truss | 14 sets | 3.00 m | 50×3.0 | CL30,289*50 | 14pcs |
| 2.00 m | 50×3.0 | CL30,289*50 | 14pcs |
| 2.70 m | 50×3.0 | CL30,289*50 | 14pcs |
| Roof Components | 4 | roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs |
| 5 | roof conner 5 ways, use for roof beam truss | CS289×289 | 0pcs |
| 1 | Connect plate with clamp | CS289×289 | 2pcs |
| Single clamp | 28pcs |
| Double clamp | 8pcs |
| roof canopy material:pvc, Blue Colour or customized. | 346.86 | 1pcs |
