18x24x8m Heavy-Duty Aluminum Outdoor Event Roof Truss System - 8m High Double-Grid Concert Stage Structure

5 0 Reviews

Massive 18m x 24m aluminum outdoor event roof truss system standing 8m high. Featuring a robust double-grid design (two 12m deep sections), this professional stage structure is engineered for large-scale festivals, stadium concerts, and high-capacity rigging requirements.

Price: ￥ 180012


Availability:



Inquire

Brand:
Dragonstage

Product Description

Heavy-Duty Aluminum Outdoor Event Roof Truss System

packing weight:4153kg

packing volume:50cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
18.00 m Beam(front)	3 sets	3.00 m	50×3.0	CS500×600	18pcs
		2.00 m	50×3.0	CS500×600	0pcs
		1.00 m	50×3.0	CS500×600	0pcs
24.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS500×600	16pcs
		2.00 m	50×3.0	CS500×600	0pcs
		1.00 m	50×3.0	CS500×600	0pcs
7.00 m Pillar	6 sets	3.00 m	50×3.0	CS389×389	12pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	6pcs
beam cube	6 faces	CS500×600			0pcs
Frame Tower	Spigot Sleeve Block M				6pcs
	Steel Base M				6pcs
	Top Section M				6pcs
	Manual hoist,BA05 2Tons				6pcs
	Spigot Hinge Section,Height 1m				6pcs
	Fibre sling,BA04,2 tons 3m				6pcs
	Long outrigger				24pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
Roof Pillar	3 sets	1.80 m	50×3.0	CS289×289	3pcs
24.00 m Top Beam	1 sets	3.00 m	50×3.0	CS289×289	8pcs
		2.00 m	50×3.0	CS289×289	0pcs
		1.00 m	50×3.0	CS289×289	0pcs
9.20 m Oblique Beam	6 sets	3.00 m	50×3.0	CS289×289	12pcs
		2.00 m	50×3.0	CS289×289	6pcs
		1.20 m	50×3.0	CS289×289	6pcs
9.20 m Ladder truss	20 sets	3.00 m	50×3.0	CL30,289*50	40pcs
		2.00 m	50×3.0	CL30,289*50	20pcs
		1.20 m	50×3.0	CL30,289*50	20pcs
Roof Components	4	roof conner 4 ways, use for roof beam truss		CS289×289	2pcs
	5	roof conner 5 ways, use for roof beam truss		CS289×289	1pcs
	1	Connect plate with clamp		CS289×289	3pcs
		Single clamp			40pcs
		Double clamp			12pcs
		roof canopy material:pvc, Blue Colour or customized.		599.76	1pcs

This Professional 18m x 24m Double-Grid Aluminum Roof Truss System is a top-tier structural solution designed for elite-level outdoor event productions. By utilizing an advanced double-grid architecture, this system provides a vast 432-square-meter overhead platform capable of supporting complex technical riders.

Double-Grid Modular Engineering: The structure is composed of two interconnected 12m deep by 18m wide grids, creating a total professional footprint of 24 meters in depth and 18 meters in width.
Professional Elevation: Standing at a towering 8-meter height, this system provides the necessary vertical clearance for large-format LED screens, elaborate lighting rigs, and professional stage scenery.
Superior Structural Support: Built on a multi-tower ground support configuration, the system utilizes heavy-duty vertical pillars with reinforced outriggers and industrial-grade base plates to ensure rock-solid stability on outdoor terrain.
Pitched Roof Design: The gable-style roof architecture is engineered for optimal weight distribution and efficient water drainage, protecting the stage and sensitive electronic equipment from environmental factors.
High-Load Capacity: Fabricated from high-strength 6061-T6 aluminum alloy, offering an industry-leading strength-to-weight ratio for the safe suspension of massive line arrays and complex lighting arrays.
Versatile Large-Scale Application: The definitive choice for outdoor music festivals, major corporate brand activations, and touring concert productions requiring a high-impact visual presence.
