CXM-11
Dragon Stage
Aluminum Curved Triangle Roof Stage Truss System 6x5x6m
this shape of roof stage truss system is a typical model welcomed by most clients. because it has strong roof to prevent sunshine and rain.
| Item | Specification(squre truss) | Qty | ||||||
| length | main tube(mm) | size(mm) | ||||||
| 6.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 4 pcs | |||
| 2.00 m | 50×3.0 | CS289×289 | pcs | |||||
| 1.00 m | 50×3.0 | CS289×289 | pcs | |||||
| 5.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS289×289 | 2 pcs | |||
| 2.00 m | 50×3.0 | CS289×289 | 2 pcs | |||||
| 1.00 m | 50×3.0 | CS289×289 | pcs | |||||
| 5.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 4 pcs | |||
| 2.00 m | 50×3.0 | CS289×289 | 8 pcs | |||||
| 1.00 m | 50×3.0 | CS289×289 | pcs | |||||
| Frame Tower | Spigot Sleeve Block S | 4 pcs | ||||||
| Steel Base S | 4 pcs | |||||||
| Top Section S | 4 pcs | |||||||
| Manual hoist,BA05 2Tons | 4 pcs | |||||||
| Spigot Hinge Section,Height 1m | 4 pcs | |||||||
| Fibre sling,BA04,2 tons 3m | 4 pcs | |||||||
| Long outrigger | 16 pcs | |||||||
| Item | Specification(squre truss) | Qty | ||||||
| length | main tube(mm) | size(mm) | ||||||
| Roof Pillar | 2 sets | .60 m | 50×3.0 | CS289×289 | 2 pcs | |||
| 5.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 1 pcs | |||
| 2.00 m | 50×3.0 | CS289×289 | 1 pcs | |||||
| 1.00 m | 50×3.0 | CS289×289 | pcs | |||||
| 3.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | pcs | |||
| 2.00 m | 50×3.0 | CS289×289 | 4 pcs | |||||
| 1.20 m | 50×3.0 | CS289×289 | 4 pcs | |||||
| 3.20 m Ladder truss | 4 sets | 3.00 m | 50×3.0 | CL30,289*50 | pcs | |||
| 2.00 m | 50×3.0 | CL30,289*50 | 4 pcs | |||||
| 1.20 m | 50×3.0 | CL30,289*50 | 4 pcs | |||||
| Roof Components | roof conner 4 ways, use for roof beam truss | CS289×289 | 2 pcs | |||||
| roof conner 5 ways, use for roof beam truss | CS289×289 | pcs | ||||||
| Connect plate with clamp | 2 pcs | |||||||
| Single clamp | 8 pcs | |||||||
| Double clamp | 8 pcs | |||||||
| roof canopy material:pvc, Blue Colour or customized. | 72.56 | 1 pcs | ||||||
packing weight: 1200kg
packing volume: 9cbm
For small-to-medium events that require a high-impact visual presence without a massive footprint, the DragonStage 6x5x6m Aluminum Curved Triangle Roof Truss is the ideal solution. Combining a compact 30-square-meter floor area with a commanding 6-meter vertical height, this system provides the clearance needed for professional lighting effects and clear sightlines. The curved "arc" roof design offers a modern aesthetic that stands out at fashion shows, DJ performances, and corporate promotions, providing a professional rigging environment in spaces where larger stadium rigs cannot fit.
One of the primary challenges with smaller outdoor rigs is achieving professional height while maintaining structural stability. A 6-meter tall structure with a 6-meter width has a high center of gravity, making it sensitive to lateral wind forces. Additionally, small event organizers often operate with limited crews, making setup speed and ease of assembly critical.1
DragonStage addresses these needs by utilizing high-strength 6082-T6 aluminum alloy in a precision-engineered spigot or bolt configuration.2 The system features a ground-support tower design that allows the roof and lighting rig to be assembled at ground level and safely elevated using manual chain hoists. To ensure stability, we provide reinforced steel bases and outriggers that broaden the footprint, ensuring the 6-meter height remains secure even in breezy outdoor environments. The curved roof architecture is not just for style; it ensures rapid water drainage, preventing the "water bag" effect that can stress flat-roof canopies during rain (Source:https://www.dragontruss.com/Aluminum-Truss-pl3962133.html).
The 6x5x6m curved roof truss is a versatile asset designed for rapid deployment and multi-year durability.
The curved triangle roof provides superior structural tension for the PVC canopy. This high-tension fit ensures the roof remains quiet in the wind and sheds water instantly. The arc design also provides a unique mounting angle for lighting fixtures, allowing for more creative front-of-house and back-lighting positions compared to standard square rigs (Source:https://www.dragontruss.com/Lighting-Truss-pl3552133.html).
Designed for the "working professional," the components of this 6x5x6m kit are optimized for transport. The modular truss sections are lightweight yet offer high load-bearing capacity. By using a synchronized sleeve block system, a small crew can have the entire structure ready for flight in approximately 2 to 3 hours, significantly reducing labor costs for one-day events (Source:https://www.dragontruss.com/Stage-Truss-pl3452133.html).
Every DragonStage 6x5x6m system is manufactured to meet rigorous international safety standards. With TUV and CE certifications, event organizers can provide the necessary structural documentation for local fire marshals and insurance providers. The flame-retardant PVC canopy and corrosion-resistant aluminum frame ensure that the system remains a safe, professional-looking investment for years to come (Source:https://www.dragontruss.com/TUV-Report-dc249965.html).
| Question | Answer |
| Q: What is the load capacity for the 6m span? | Depending on the truss profile, the 6m span is typically rated for a distributed load of 500kg-800kg, perfect for professional lighting. |
| Q: Can this be used without the roof canopy? | Yes, the aluminum frame can be used as a standalone lighting rig for indoor events where weather protection isn't needed. |
| Q: What ballast is recommended for the 6m height? | We recommend at least 200kg of ballast per tower for outdoor use, depending on local wind conditions. |
| Q: Are the hoists manual or electric? | The standard package includes manual chain hoists, but it is fully compatible with electric motor upgrades. |
Enhance your small-scale productions with a structure that delivers big-stage professional impact. Trust DragonStage for the perfect balance of height, style, and safety.
Contact the DragonStage sales team today for a custom quote or download the 6x5x6m load-bearing specifications to plan your next event.
