8x6x6m Outdoor Concert Lighting Truss System

5 0 Reviews

Elevate your event with our 8m x 6m assembly aluminum mobile stage truss system. Standing 6m high, this professional rig features dual 2m wide speaker wings for line array suspension and a modular ground support design. Perfect for outdoor concerts, festivals, and corporate events requiring a stable 48sqm performance area and high-capacity lighting suspension.

Price: ￥ 40580


Availability:



Inquire

Brand:
Dragonstage

Product Description

What is an Outdoor Concert Lighting Truss System?

An outdoor concert lighting truss system is a modular aluminum structure designed to support stage lighting, LED screens, and audio equipment in open-air environments. This 8x6x6m system is engineered for stability, weather resistance, and efficient load distribution, making it ideal for concerts, festivals, and large-scale events.

To better understand how truss systems function in real events, see What is truss in event? and How does a truss system work for events?.

Product Type: Outdoor Lighting Truss System
Size: 8m (W) × 6m (D) × 6m (H)
Material: Aluminum Alloy (High-strength structural grade)
Structure: Modular Spigot Truss System
Application: Concerts, festivals, outdoor stage events
Load Capacity: Depends on configuration and rigging design (see load capacity / load analysis)
Installation: Modular assembly system (see assembly / installation methodology)

This Professional 8m x 6m Assembly Aluminum Mobile Stage Truss System is an industrial-grade structural solution designed for high-impact live performances and specialized event production. Engineered for rapid assembly and maximum durability, this system provides a secure environment for complex lighting and audio-visual deployments.

8x6x6m Outdoor Concert Lighting Truss System

packing weight:1270kg

packing volume:9cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
8.00 m Beam(front)	2 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	2pcs
		1.00 m	50×3.0	CS289×289	0pcs
6.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	0pcs
		1.00 m	50×3.0	CS289×289	0pcs
5.00 m Pillar	4 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	4pcs
		1.00 m	50×3.0	CS289×289	0pcs
beam cube	6 faces	CS289×289			0pcs
Frame Tower	Spigot Sleeve Block S				4pcs
	Steel Base S				4pcs
	Top Section S				4pcs
	Manual hoist,BA05 2Tons				4pcs
	Spigot Hinge Section,Height 1m				4pcs
	Fibre sling,BA04,2 tons 3m				4pcs
	Long outrigger				16pcs

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
2.00 m Wings Beam	2 sets	3.00 m	50×3.0	CS289×289	0pcs
		2.00 m	50×3.0	CS289×289	2pcs
		1.00 m	50×3.0	CS289×289	0pcs
5.00 m Wings Pillar	2 sets	3.00 m	50×3.0	CS289×289	2pcs
		2.00 m	50×3.0	CS289×289	2pcs
		1.00 m	50×3.0	CS289×289	0pcs
Wings Tower	Spigot Sleeve Block S				2pcs
	Steel Base S				2pcs
	Top Section S				2pcs
	Manual hoist,BA05 2Tons				2pcs
	Spigot Hinge Section,Height 1m				2pcs
	Fibre sling,BA04,2 tons 3m				2pcs
	Long outrigger				8pcs
Truss Accessory		Conical coupler & Safrty clip & pin			whole set

Why This 8x6x6m Lighting Truss System Is Recommended

This system is designed based on real-world event engineering requirements, balancing structural safety, transport efficiency, and fast installation.

Stable outdoor structure
Designed for wind resistance and uneven ground conditions. Learn more about Outdoor Lighting Truss Guide.
Optimized load performance
Built using high-quality aluminum alloy, ensuring strength-to-weight efficiency. See Why people choose aluminium truss rather than iron truss.
Flexible modular design
Easy to expand or reconfigure for different stage layouts. Related system logic explained in modular design / modular system logic.
Industry-standard connection system
Uses reliable spigot or bolt connection systems. See Connection & Material System.

Structural Design and Safety Considerations

The performance of a lighting truss system depends not only on size but also on material quality, connection design, and load distribution.

Aluminum grade selection affects structural strength. See 6061-T6 vs 6082-T6 Aluminum
Incorrect material assumptions can lead to failure. See Using Incorrect Aluminum Data in Structural Design
Welding quality directly impacts safety. See Aluminum Welding Quality Engineering Hub

For a complete system-level understanding, refer to the Complete Engineering Guide for Event Truss System Planning.

Where This Truss System Is Used

This 8x6x6m outdoor truss system is widely applied in:

Large outdoor concerts → see concert event stage application
Touring productions → see Temporary Stage Truss Systems for Touring Productions
Festival stages and public events
Exhibition and brand events → see Exhibition Booth Solution

Explore more use cases at application scenarios.

FAQ

What is the load capacity of this truss system?

The load capacity depends on span, height, and rigging method. For detailed calculation principles, see What is the maximum load capacity of a event aluminum truss system?.
