Heavy-Duty Aluminum Stage Truss System 12x8x6m Professional Concert Roof

5 0 Reviews

Discover our robust 12m x 8m aluminum concert stage roof truss system. Standing 6m high, this professional-grade square box truss structure offers unmatched stability and durability for music festivals and large outdoor events.

Price: ￥ 51440


Availability:



Inquire

Brand:
Dragonstage

Product Description

Elevate your large-scale productions with this professional Square Box Truss Quality Music Festival Roof Truss System. Engineered from high-grade, lightweight aluminum alloy (6061-T6 or 6082-T6), this structure is designed to support significant loads while resisting corrosion for long-term outdoor use. It provides the open space and attachment points needed for modern lighting and audiovisual designs, making it an essential component for any major event.

Key Features & Specifications

Dimensions: A substantial structure measuring 12 meters in length by 8 meters in depth, with a towering 6-meter height.
Material: Constructed from durable aluminum alloy, ensuring a sturdy yet lightweight framework.
Design: Utilizes a square box truss design, known for high loading capacities and structural integrity.
Assembly: Designed for efficient setup and breakdown, with quick and simple connection systems (spigot or bolt type).
Versatility: Ideal for a wide range of applications including music festivals, concerts, corporate events, and exhibitions.

Ensure safety and visual impact at your next event with this high-quality truss system.

Heavy-Duty Aluminum Stage Truss System 12x8x6m Professional Concert Roof

packing weight:1360kg

packing volume:20cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
12.00 m Beam(front)	2 sets	3.00 m	50×3.0	CS389×389	8pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
8.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS389×389	4pcs
		2.00 m	50×3.0	CS389×389	2pcs
		1.00 m	50×3.0	CS389×389	0pcs
8.00 m Ladder truss	7 sets	3.00 m	50×3.0	CL30,289*50	14pcs
		2.00 m	50×3.0	CL30,289*50	7pcs
		1.00 m	50×3.0	CL30,289*50	0pcs
5.00 m Pillar	4 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	4pcs
		1.00 m	50×3.0	CS289×289	0pcs
beam cube	6 faces	CS389×389			0pcs
Frame Tower	Spigot Sleeve Block S				4pcs
	Steel Base S				4pcs
	Top Section S				4pcs
	Manual hoist,BA05 2Tons				4pcs
	Spigot Hinge Section,Height 1m				4pcs
	Fibre sling,BA04,2 tons 3m				4pcs
	Long outrigger				16pcs
	0.5	roof conner 2 ways, use for roof beam truss		CS389×389	4pcs
		Single clamp			28pcs
		roof canopy material:pvc, Blue Colour or customized.		140	1pcs
