packing weight: 1800kg
packing volume: 17cbm
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| 16.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | CS389×389 | 10pcs |
| 2.00 m | 50×3.0 | CS389×389 | 0pcs |
| 1.00 m | 50×3.0 | CS389×389 | 2pcs |
| 8.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | CS389×389 | 4pcs |
| 2.00 m | 50×3.0 | CS389×389 | 2pcs |
| 1.00 m | 50×3.0 | CS389×389 | 0pcs |
| 6.00 m Pillar | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| beam cube | Spigot cube 389x389 | 0pcs |
| Frame Tower | Spigot Sleeve Block S | 4pcs |
| Steel Base S | 4pcs |
| Top Section S | 4pcs |
| Manual hoist,BA05 2Tons | 4pcs |
| Spigot Hinge Section,Height 1m | 4pcs |
| Fibre sling,BA04,2 tons 3m | 4pcs |
| Long outrigger | 16pcs |
| Item |
| Specification(squre truss) | Qty |
| length | main tube(mm) | size(mm) |
| Roof Pillar | 2 sets | 1.60 m | 50×3.0 | CS289×289 | 2pcs |
| 8.00 m Top Beam | 1 sets | 3.00 m | 50×3.0 | CS289×289 | 2pcs |
| 2.00 m | 50×3.0 | CS289×289 | 1pcs |
| 1.00 m | 50×3.0 | CS289×289 | 0pcs |
| 8.20 m Oblique Beam | 4 sets | 3.00 m | 50×3.0 | CS289×289 | 8pcs |
| 2.00 m | 50×3.0 | CS289×289 | 0pcs |
| 2.20 m | 50×3.0 | CS289×289 | 4pcs |
| 8.20 m Ladder truss | 6 sets | 3.00 m | 50×3.0 | CL30,289*50 | 12pcs |
| 2.00 m | 50×3.0 | CL30,289*50 | 0pcs |
| 2.20 m | 50×3.0 | CL30,289*50 | 6pcs |
| Roof Components |
| roof conner 4 ways, use for roof beam truss | CS289×289 | 2pcs |
| roof conner 5 ways, use for roof beam truss | CS289×289 | 0pcs |
| Connect plate with clamp | 2pcs |
| Single clamp | 12pcs |
| Double clamp | 8pcs |
| roof canopy material:pvc, Blue Colour or customized. | 236.96 | 1pcs |
Affordable 16x8x7m Aluminum Flat Rooftop Truss with Outdoor Concert Stage1
1. Introduction
For event organizers balancing a large-scale vision with a strict budget, the DragonStage 16x8x7m Aluminum Flat Rooftop Truss System offers a high-impact, cost-effective solution. This expansive system provides a 16-meter wide performance area, 8 meters of depth, and a 7-meter vertical clearance, making it suitable for regional festivals, community concerts, and large corporate rallies. By offering a "cheap" or "used" alternative without compromising on core structural 6061-T6 aluminum quality, DragonStage provides an accessible entry point for professional-grade outdoor stage production.
2. Industry Challenges & Technical Solutions
Large-span structures typically face two major hurdles: structural deflection and weather management. A 16-meter horizontal span is subject to significant gravitational stress when loaded with heavy lighting rigs and LED screens. Furthermore, "flat" roof designs are notorious for collecting rainwater if the canopy is not engineered correctly.
DragonStage addresses these challenges through reinforced pillar supports and high-strength sleeve blocks. Even in our budget-friendly configurations, we utilize heavy-duty aluminum alloys that maintain rigidity across the 16m span. To solve the drainage issue associated with flat roofs, our PVC canopies are designed with high-tension fastening points, ensuring the fabric remains taut enough to shed water toward the periphery. This prevents the dangerous accumulation of water that can lead to structural failure. Additionally, the integrated stage system features adjustable leveling jacks, allowing the 16x8m platform to remain perfectly stable even on uneven outdoor terrain.
3. Key Features & Operational Benefits
The 16x8x7m flat roof system is designed for maximum square footage and operational efficiency.
High-Capacity 6061-T6 Aluminum Framework
Despite being positioned as an affordable option, the structure is built from industry-standard 6061-T6 aluminum. This ensures the system remains lightweight for transport while offering the high tensile strength required for hanging line arrays and lighting fixtures. The modular nature of the truss allows for the 16m width to be broken down into manageable sections, making it a highly portable asset for touring companies (Source:https://www.dragontruss.com/Aluminum-Truss-pl3962133.html).
Integrated Professional Stage System
This package includes a full 16x8m modular outdoor stage. The stage decks are designed with anti-slip, waterproof surfaces and are engineered to lock directly into the truss pillars for enhanced structural unity. This integration ensures that the stage and the roof move as a single unit, providing a safer environment for performers and reducing the setup time typically associated with independent stage and roof builds (Source:https://www.dragontruss.com/Stage-Truss-pl3452133.html).
Certified Safety and Budget Versatility
DragonStage ensures that even "used" or "cheap" systems undergo rigorous quality checks. All components adhere to international welding and safety standards. For organizations requiring documented safety for permits, our manufacturing processes are backed by TUV reporting, ensuring that your budget-friendly investment meets the safety requirements of modern insurance and venue regulations (Source:https://www.dragontruss.com/TUV-Report-dc249965.html).
4. Practical FAQ for Stage Professionals
| Question | Answer |
| Q: What is the maximum load capacity for the 16m beam? | The load capacity depends on the specific truss profile used. We provide detailed load charts for every 16m span to ensure safe equipment rigging. |
| Q: How do you prevent water from pooling on a flat roof? | We use a high-tension PVC canopy and a slightly offset height adjustment on the towers to create a subtle slope for water runoff. |
| Q: Does "used" mean the truss is damaged? | No. Used systems are structurally inspected, cleaned, and verified for integrity. They offer a lower price point due to cosmetic wear or previous rental history. |
| Q: How long does it take to set up the 16x8m system? | A trained crew of 4 to 6 people can typically complete the full stage and roof assembly in approximately 5 to 7 hours. |
5. Strong Call to Action (CTA)
Bring professional scale to your event without the premium price tag. Trust DragonStage to provide the durable, large-span structures your festival deserves.
Contact the DragonStage sales team today for a quote on our 16x8x7m flat roof truss packages and secure a high-quality stage for your next production.
