13x8x7m Professional Aluminum Arched Roof Concert Stage

5 0 Reviews

Premier 13m x 8m aluminum arched roof concert stage system standing 7m high. Featuring a reinforced 4-pillar ground support design and a high-tension curved canopy frame for superior weather drainage. Engineered for professional outdoor festivals, concerts, and major corporate events requiring massive vertical clearance and structural reliability.

Price: ￥ 71853


Availability:



Inquire

Brand:
Dragonstage

Product Description

This Professional 13m x 8m Arched Roof Concert Stage is an elite structural solution designed for high-impact outdoor productions and professional music festivals. Combining a spacious 104-square-meter performance area with a towering 7-meter elevation, this system provides a comprehensive, weather-protected environment for headlining acts.

13x8x7m Professional Aluminum Arched Roof Concert Stage

packing weight:1715kg

packing volume:15cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
13.00 m Beam(front)	2 sets	3.00 m	50×3.0	CS389×389	8 pcs
		2.00 m	50×3.0	CS389×389	pcs
		1.00 m	50×3.0	CS389×389	2 pcs
8.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS389×389	4 pcs
		2.00 m	50×3.0	CS389×389	2 pcs
		1.00 m	50×3.0	CS389×389	pcs
7.00 m Pillar	4 sets	3.00 m	50×3.0	CS289×289	8 pcs
		2.00 m	50×3.0	CS289×289	pcs
		1.00 m	50×3.0	CS289×289	4 pcs
Tower	Spigot Sleeve Block S				4 pcs
	Steel Base S				4 pcs
	Top Section S				4 pcs
	Manual hoist,BA05 2Tons				4 pcs
	Spigot Hinge Section,Height 1m				4 pcs
	Fibre sling,BA04,2 tons 3m				4 pcs
	Long outrigger				16 pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
Roof Pillar	sets	1.30 m	50×3.0	CS289×289	pcs
8.00 m Top Beam	1 sets	3.00 m	50×3.0	CS289×289	2 pcs
		2.00 m	50×3.0	CS289×289	1 pcs
		1.00 m	50×3.0	CS289×289	pcs
15.00 m Arch Beam	4 sets	3.00 m	50×3.0	CS289×289	16 pcs
		2.00 m	50×3.0	CS289×289	pcs
		1.50 m	50×3.0	CS289×289	8 pcs
15.00 m Ladder truss	sets	3.00 m	50×3.0	CL40,389*50	pcs
		2.00 m	50×3.0	CL40,389*50	pcs
		1.50 m	50×3.0	CL40,389*50	pcs
Roof Components		spigot multi cube, use for roof beam truss		CS289×289	pcs
		Connect plate with clamp			pcs
		Single clamp			pcs
		Double clamp			16 pcs
		roof canopy material:pvc, Blue Colour or customized.		231.08	1 pcs
