Premium 12m x 12m aluminum event truss tent system standing 10m high. Featuring a reinforced 4-pillar ground support design and a high-tension waterproof canopy. Engineered for professional outdoor festivals, corporate exhibitions, and large-scale temporary venues requiring maximum vertical clearance and structural reliability.
packing weight:1550kg
packing volume:24cbm
| Item | Specification(squre truss) | Qty | ||||||
| length | main tube(mm) | size(mm) | ||||||
| 12.00 m Beam(front) | 2 sets | 3.00 m | 50×3.0 | BS500×600 | 8pcs | |||
| 2.00 m | 50×3.0 | BS500×600 | 0pcs | |||||
| 1.00 m | 50×3.0 | BS500×600 | 0pcs | |||||
| 8.00 m Beam(side) | 2 sets | 3.00 m | 50×3.0 | BS500×600 | 4pcs | |||
| 2.00 m | 50×3.0 | BS500×600 | 2pcs | |||||
| 1.00 m | 50×3.0 | BS500×600 | 0pcs | |||||
| 11.00 m Pillar | 4 sets | 3.00 m | 50x3.0 | BS350×350 | 16pcs | |||
| 2.00 m | 50x3.0 | BS350×350 | 4pcs | |||||
| 1.00 m | 50x3.0 | BS350×350 | 0pcs | |||||
| beam cube | cube 500x600 | 1pcs | ||||||
| Frame Tower | Bolt Truss Sleeve Block M | 4pcs | ||||||
| Steel Base M | 4pcs | |||||||
| Top Section M | 4pcs | |||||||
| Manual hoist,BA05 2Tons | 4pcs | |||||||
| Spigot Hinge Section,Height 1m | 4pcs | |||||||
| Fibre sling,BA04,2 tons 3m | 4pcs | |||||||
| Long outrigger | 16pcs | |||||||
