High-Grade 14x14x10m Outdoor Stage Roof Truss for Large-Scale Events

1. Introduction

Large-scale outdoor festivals and high-impact corporate events require a structural foundation that provides both massive scale and uncompromised safety. The High-Grade 14x14x10m Outdoor Stage Roof Truss by DragonStage is engineered for elite production environments, offering a 196-square-meter covered performance area. With a commanding 10-meter vertical clearance, this system provides the overhead volume necessary for tiered lighting plots, high-resolution LED backdrops, and complex audio rigging. For stage builders and event organizers, the challenge is finding a rig that supports heavy technical riders while resisting the unpredictable forces of nature—a challenge this precision-engineered aluminum system meets with industrial excellence.

2. Challenges & Solutions

One of the primary challenges for 14-meter spans is managing structural deflection. Traditional trussing can "sag" under the weight of heavy moving heads and LED panels; DragonStage solves this by using high-grade, reinforced aluminum profiles that maintain a rigid horizontal line across the entire span. Additionally, at a 10-meter height, wind resistance becomes a critical safety factor. Our solution features a multi-tower ground support system and integrated outriggers that anchor the structure firmly against lateral wind loads. For crews facing tight festival timelines, the modular design and sleeve-block system allow the entire roof grid to be rigged at ground level and safely hoisted, significantly reducing on-site labor and enhancing crew safety.

3. Key Features & Benefits

The 14x14x10m system is manufactured from aerospace-grade 6082-T6 aluminum alloy. This material is specifically chosen for its high tensile strength and superior resistance to corrosion, ensuring the structure remains a safe and professional asset in humid or coastal environments (Source:https://www.dragontruss.com/Aluminum-Truss-System-pd413987768.html).

The system features a pitched roof design covered by a heavy-duty, fire-retardant 850g/m² PVC canopy. This geometry ensures immediate water runoff, preventing the dangerous accumulation of water pockets during heavy rain. According to international safety standards for temporary event structures, a 10-meter high structure requires precise ballast calculations to prevent tipping, which is why our tower bases are compatible with high-capacity weight systems (Source:https://www.lsionline.com).

To ensure a complete performance environment, this trussing is perfectly compatible with our modular aluminum stage platforms. These decks feature 18mm anti-slip surfaces and adjustable legs, providing a stable foundation that matches the professional grade of the overhead rig (Source:https://www.dragontruss.com/Aluminum-Stage-Platform-pd463987768.html). This total-system approach ensures structural harmony from the ground to the 10-meter peak.

4. FAQ Section

Q: What is the maximum load the 14m span can support?A: Depending on the truss profile selected, the 14m span can typically support between 1,500kg and 2,500kg of distributed load for lighting and audio.

Q: Can this structure be used in high-wind areas?A: Yes. When used with proper ballast and guy-wires, the system is designed for high-wind stability. We recommend removing the canopy if winds are forecasted to exceed 70km/h.

Q: How is the roof grid raised to 10 meters?A: The system utilizes a tower lift system with sleeve blocks and can be operated using synchronized electric chain hoists or manual winches.

Q: Is the PVC canopy fire-retardant?A: Absolutely. Our canopies are waterproof, UV-resistant, and meet international B1/M2 fire-retardant safety standards.

5. Strong Call to Action (CTA)

Ensure your next production is built on a foundation of elite engineering and absolute safety. Contact DragonStage’s engineering team today for a custom quote on the 14x14x10m High-Grade Outdoor Stage Roof Truss. Download our detailed technical specifications and start planning your most successful event season yet.
