packing weight:450kg
packing volume:4cbm
| Item | Specification(squre truss) | Qty | |||||
| length(M) | main tube(MM) | size(MM) | |||||
| Beam | 3 | 50×3.0 | CS389×389 | 2 pcs | |||
| 2 | 50×3.0 | CS389×389 | pcs | ||||
| 1 | 50×3.0 | CS389×389 | pcs | ||||
| 0.5 | 50×3.0 | CS389×389 | pcs | ||||
| Pillar | 3 | 50×3.0 | CS289×289 | 6 pcs | |||
| 2 | 50×3.0 | CS289×289 | pcs | ||||
| 1 | 50×3.0 | CS289×289 | pcs | ||||
| 0.5 | 50×3.0 | CS289×289 | pcs | ||||
| Tower | Spigot Sleeve Block S | 2 pcs | |||||
| Steel Base S | 2 pcs | ||||||
| Top Section S | 2 pcs | ||||||
| Manual hoist,BA05 2Tons | 2 pcs | ||||||
| Spigot Hinge Section,Height 1m | 2 pcs | ||||||
| Fibre sling,BA04,2 tons 3m | 2 pcs | ||||||
| Long outrigger | 8 pcs | ||||||
| Truss Accessory | Conical coupler & Safrty clip & pin | whole set | |||||
This Professional Goal Post Aluminum Truss System provides a reliable and high-reaching rigging solution for large-format LED displays and video walls. Its slim-profile yet incredibly strong "goal post" or gantry configuration is ideal for events where a full roof system is not required but high-impact visual height is essential.
Massive Visual Impact: With a 10-meter height, this structure ensures your LED content is visible from a great distance, making it perfect for festival secondary screens, outdoor cinema setups, or sporting event displays.
Optimal Width for Screens: The 6-meter width comfortably accommodates standard large-scale LED panels, providing a stable frame for rigging heavy video equipment.
High-Stability Gantry Design: The system features two vertical support towers equipped with extended outriggers (stabilizers) and heavy-duty base plates to ensure the structure remains upright and secure even at full height.
Professional Rigging: The horizontal beam is designed to be lifted via manual or electric chain hoists, allowing for ground-level screen assembly and safe elevation to the 10m peak.
Durable Construction: Manufactured from high-grade 6082-T6 aluminum alloy, offering an exceptional strength-to-weight ratio and natural resistance to corrosion for all-weather outdoor use.
