| Power supply | 100-240V - 50/60Hz |
| Power consumption | 300W, PFC: 99% |
| LED source | 16 x 15W RGBW 4in1 |
| Luminous flux | >9000lm |
| Field angle | Optional 6°, 15°, 20°, 25°, 45° |
| Optic | High efficiency optic system |
| Special feature | Invert lighting
User color
Free lightCON
Software update |
| Dimmer mode | 8 & 16 Bit |
| DMX mode | 11 / 27 / 64 / 75CH |
| Control mode | DMX, Auto, Master-slave |
| Protocol | DMX, RDM |
| Light style | Pixel-mapping
Multi-layer
Dynamic patterns
|
| IP rating | 65 |
| Working Condition | -30° ~ 70°C |
| Power & DMX link | - PowerCON True1 in & out
- 3 or 5pin DMX in & out |
| Box Info | - Carton: 2 in 1
- Case: 4 in 1 / 8 in 1 |
| Size(mm) | - L1004 x W96 x H130
- 1330 x 290 x 200 |
| Weight(kg) | - Net Weight: 9 (Gross 2in1 21)
- Case Weight: Customized |
| Optional Accessories | - Flying case
- Clamp
- Barndoor
- Mask face
- PMMA froster, PMMA cover
- Stand & Hang components
- Stand Plate
- P-Engine |
