40x40x30 ft Aluminum Podium for Concert

5 3 Reviews

12x12x9m concert stage

this is a custom 40 feet by 40 feet truss stage for clients event, the height of truss system is 30 feet, with 2 speaker wings wide 6.56 feet.

the concert stage platform is 32 x32 feet, 9.76 x9.76m height 1.2-2m with 2 stairs

Price: ￥ 48770 - 140692


features:	roof truss system concert stage motor roof truss system
Availability:



Inquire

Brand:
Dragon Stage

Product Description

The DragonStage 40 × 40 × 30ft Aluminum Concert Stage Truss System is a custom-built stage package developed for concert and live-event applications where the customer needs a large performance platform together with an overhead aluminum truss structure and dedicated side areas for speaker support.

The nominal truss-system dimensions are:

Width: 40ft
Depth: 40ft
Height: 30ft

This is commonly described in metric terms as approximately 12m × 12m × 9m.

Inside the truss structure, the main performance stage measures:

32ft × 32ft
approximately 9.76m × 9.76m
adjustable / selectable stage height of approximately 1.2–2m
2 access stairs

Two side speaker wings, each approximately 6.56ft (2m) wide, extend the system for audio-support applications.

For other large event truss structures, see our Aluminum Truss and Stage Truss ranges.

Main Specifications

Item	Specification
Product Type	Aluminum Concert Stage Truss System
Nominal Truss Width	40ft
Nominal Truss Depth	40ft
Nominal Truss Height	30ft
Approx. Metric Size	12 × 12 × 9m
Stage Platform Size	32 × 32ft
Approx. Metric Stage Size	9.76 × 9.76m
Stage Height	Approx. 1.2–2m
Access	2 Stairs
Speaker Wings	2
Speaker Wing Width	Approx. 6.56ft / 2m each
Main Structure	Aluminum Truss
Main Application	Concert / Festival / Live Event
Custom Manufacturing	Available
Brand	DragonStage

packing weight: 2050kg

packing volume: 13cbm

Item	Specification				Quantity
Aluminium assembly stage	topping: 4x8ft (1.22x2.44m)		wooden		32 pcs
	1.22m stage brace				40 pcs
	2.44m stage brace				36 pcs
	stand with extendable tube				45 pcs
	Stage adjustable base				45 pcs
Stage Stair	wooden topping	total	8	steps	2 pcs

packing weight: 2900kg

packing volume: 21cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
12.00 m Beam(front)	3 sets	3.00 m	50×3.0	CS389×389	12pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
12.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS389×389	8pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
8.00 m Pillar	6 sets	3.00 m	50×3.0	CS289×289	12pcs
		2.00 m	50×3.0	CS289×289	6pcs
		1.00 m	50×3.0	CS289×289	0pcs
beam cube	Spigot cube 389x389				0pcs
Frame Tower	Spigot Sleeve Block S				6pcs
	Steel Base S				6pcs
	Top Section S				6pcs
	Manual hoist,BA05 2Tons				6pcs
	Spigot Hinge Section,Height 1m				6pcs
	Fibre sling,BA04,2 tons 3m				6pcs
	Long outrigger				24pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
Roof Pillar	3 sets	1.20 m	50×3.0	CS289×289	3pcs
12.00 m Top Beam	1 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	0pcs
		1.00 m	50×3.0	CS289×289	0pcs
6.20 m Oblique Beam	6 sets	3.00 m	50×3.0	CS289×289	6pcs
		2.00 m	50×3.0	CS289×289	6pcs
		1.20 m	50×3.0	CS289×289	6pcs
6.20 m Ladder truss	8 sets	3.00 m	50×3.0	CL30,289*50	8pcs
		2.00 m	50×3.0	CL30,289*50	8pcs
		1.20 m	50×3.0	CL30,289*50	8pcs
Roof Components		roof conner 4 ways, use for roof beam truss		CS289×289	2pcs
		roof conner 5 ways, use for roof beam truss		CS289×289	1pcs
		Connect plate with clamp			3pcs
		Single clamp			16pcs
		Double clamp			12pcs
		roof canopy material:pvc, Blue Colour or customized.		238.56	1pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
2.00 m Wings Beam	2 sets	3.00 m	50×3.0	CS389×389	0pcs
		2.00 m	50×3.0	CS389×389	2pcs
		1.00 m	50×3.0	CS389×389	0pcs
8.00 m Wings Pillar	2 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	2pcs
		1.00 m	50×3.0	CS289×289	0pcs
Wings Tower	Spigot Sleeve Block S				2pcs
	Steel Base S				2pcs
	Top Section S				2pcs
	Manual hoist,BA05 2Tons				2pcs
	Spigot Hinge Section,Height 1m				2pcs
	Fibre sling,BA04,2 tons 3m				2pcs
	Long outrigger				8pcs
Truss Accessory		Conical coupler & Safrty clip & pin			whole set

packing weight: 3000kg

packing volume: 23cbm

Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
12.00 m Beam(front)	3 sets	3.00 m	50×3.0	CS389×389	12pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
12.00 m Beam(side)	2 sets	3.00 m	50×3.0	CS389×389	8pcs
		2.00 m	50×3.0	CS389×389	0pcs
		1.00 m	50×3.0	CS389×389	0pcs
8.00 m Pillar	6 sets	3.00 m	50×3.0	CS289×289	12pcs
		2.00 m	50×3.0	CS289×289	6pcs
		1.00 m	50×3.0	CS289×289	0pcs
beam cube	Spigot cube 389x389				0pcs
Frame Tower	Spigot Sleeve Block S				6pcs
	Steel Base S				6pcs
	Top Section S				6pcs
	1 ton motor				6pcs
	Spigot Hinge Section,Height 1m				6pcs
	Fibre sling,BA04,2 tons 3m				6pcs
	Long outrigger				24pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
Roof Pillar	3 sets	1.20 m	50×3.0	CS289×289	3pcs
12.00 m Top Beam	1 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	0pcs
		1.00 m	50×3.0	CS289×289	0pcs
6.20 m Oblique Beam	6 sets	3.00 m	50×3.0	CS289×289	6pcs
		2.00 m	50×3.0	CS289×289	6pcs
		1.20 m	50×3.0	CS289×289	6pcs
6.20 m Ladder truss	8 sets	3.00 m	50×3.0	CL30,289*50	8pcs
		2.00 m	50×3.0	CL30,289*50	8pcs
		1.20 m	50×3.0	CL30,289*50	8pcs
Roof Components		roof conner 4 ways, use for roof beam truss		CS289×289	2pcs
		roof conner 5 ways, use for roof beam truss		CS289×289	1pcs
		Connect plate with clamp			3pcs
		Single clamp			16pcs
		Double clamp			12pcs
		roof canopy material:pvc, Blue Colour or customized.		238.56	1pcs
Item		Specification(squre truss)			Qty
		length	main tube(mm)	size(mm)
2.00 m Wings Beam	2 sets	3.00 m	50×3.0	CS389×389	0pcs
		2.00 m	50×3.0	CS389×389	2pcs
		1.00 m	50×3.0	CS389×389	0pcs
8.00 m Wings Pillar	2 sets	3.00 m	50×3.0	CS289×289	4pcs
		2.00 m	50×3.0	CS289×289	2pcs
		1.00 m	50×3.0	CS289×289	0pcs
Wings Tower	Spigot Sleeve Block S				2pcs
	Steel Base S				2pcs
	Top Section S				2pcs
	1 ton motor				2pcs
	Spigot Hinge Section,Height 1m				2pcs
	Fibre sling,BA04,2 tons 3m				2pcs
	Long outrigger				8pcs
Truss Accessory		Conical coupler & Safrty clip & pin			whole set
moto controller					1p

Complete Concert Stage Package

This product is best understood as an integrated stage package rather than only an aluminum truss frame.

The confirmed product concept combines:

40 × 40 × 30ft aluminum truss system
+
32 × 32ft elevated stage platform
+
2 speaker wings
+
2 stage stairs

This type of configuration is useful for buyers who want the principal concert-stage components coordinated as one project rather than purchasing the stage platform, truss and speaker-side structures separately.

For complete live-event applications, see our Concert Event solutions.

Typical Applications

This aluminum concert stage can be used for applications such as:

Outdoor concerts
Music festivals
Live bands
Public performances
Corporate productions
Ceremonies
Touring events
Temporary entertainment venues

The approximate 9.76 × 9.76m stage deck provides a substantial performance area while the surrounding truss system creates the overhead event-production framework.

Custom Manufacturing

The 40 × 40 × 30ft configuration shown here was developed as a customized project.

DragonStage can discuss changes to:

Truss width
Truss depth
Overall height
Stage width and depth
Stage height
Speaker-wing width
Stair quantity
Stair location
Aluminum truss specification
Equipment positions
Surface finish
Complete project quantity

Customers with a venue drawing or event plan can send it directly for configuration review.

Learn more about our manufacturing capability at DragonStage Custom Aluminum Stage & Truss Manufacturer.

What Information Is Needed for Quotation?

For a similar concert-stage project, please provide:

Required truss width and depth
Required truss height
Stage-platform dimensions
Required stage height
Lighting equipment list
Speaker / line-array model
Speaker quantity and weight
Required speaker-wing dimensions
LED screens, if any
Indoor or outdoor use
Installation location
Ground conditions
Drawings or reference images

Providing the actual production-equipment information is particularly important for a large stage because two projects with the same 40 × 40ft outside dimensions may still require different truss and support configurations.

Important Technical Note

The confirmed information for this product includes:

40 × 40 × 30ft nominal truss-system size
approximately 12 × 12 × 9m general metric description
32 × 32ft / approximately 9.76 × 9.76m stage platform
approximately 1.2–2m stage-height range
two speaker wings approximately 6.56ft / 2m wide
two stairs

The available information does not establish:

allowable roof or truss load
stage load capacity
maximum speaker load
wind resistance
ballast requirement
anchoring or foundation requirement
safety factor
certification
local-code compliance
engineering approval

These requirements depend on the actual equipment, site conditions and final production configuration.

FAQ

What is the overall size of this concert stage truss system?

The nominal aluminum truss structure measures approximately 40ft wide × 40ft deep × 30ft high.

Is 40 × 40 × 30ft exactly the same as 12 × 12 × 9m?

No. The metric description is an approximate rounded size. The imperial dimensions correspond to approximately 12.19 × 12.19 × 9.14m.

What is the stage-platform size?

The main performance platform measures approximately 32 × 32ft, or 9.76 × 9.76m.

What stage heights are available?

The existing project information specifies a stage height range of approximately 1.2m to 2m.

Are stairs included?

Yes. This configuration includes two stage-access stairs.

Does the system include speaker wings?

Yes. Two side speaker wings are included, each approximately 6.56ft / 2m wide.

Are speakers included?

Not automatically. The speaker wings are part of the structural configuration. Speakers, line-array frames, hoists and rigging hardware are only included when specifically listed in the quotation.
